Sony RCD-W1 - Back Panel and Audio Board Removal; Back Panel Removal; Audio Board Removal

11
RCD-W1
3-4. BACK PANEL
3-5. AUDIO BOARD
1 Four screws (3X10)
2
4
Two screws (3X8 BK
)
5 Back panel
3 Cord power
1
8
Wire (flat type) (CN102)
4 Connector (PN606)
6 Two screws (special)
9 AUDIO board
7 Three screws (special
)
5 Connector (PN201)
3 Connector (PN602)
2 Connector (PN105)
