65
RCD-W1
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
CND : Canadian model
MX : Mexican model
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
SECTION 7
ELECTRICAL PARTS LIST
Note:
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
AUDIO
* A-4727-516-A AUDIO BOARD, COMPLETE (E)
* A-4727-519-A AUDIO BOARD, COMPLETE (MX)
* A-4735-113-A AUDIO BOARD, COMPLETE (US,CND)
***************************
< CAPACITOR >
C101 1-126-947-11 ELECT 47uF 20% 35V
C102 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C103 1-126-963-11 ELECT 4.7uF 20% 50V
C104 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C105 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C106 1-126-947-11 ELECT 47uF 20% 35V
C108 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C109 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C110 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C114 1-126-965-11 ELECT 22uF 20% 50V
C115 1-126-965-11 ELECT 22uF 20% 50V
C116 1-126-965-11 ELECT 22uF 20% 50V
C117 1-126-965-11 ELECT 22uF 20% 50V
C118 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C119 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C120 1-126-947-11 ELECT 47uF 20% 35V
C121 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C122 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C123 1-126-947-11 ELECT 47uF 20% 35V
C124 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C125 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C126 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C127 1-126-947-11 ELECT 47uF 20% 35V
C128 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C129 1-126-947-11 ELECT 47uF 20% 35V
C130 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C131 1-126-965-11 ELECT 22uF 20% 50V
C132 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C133 1-126-965-11 ELECT 22uF 20% 50V
C134 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C135 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C136 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C137 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C138 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C139 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C140 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C141 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C142 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C143 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C144 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C145 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C202 1-126-933-11 ELECT 100uF 20% 16V
C203 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C204 1-126-947-11 ELECT 47uF 20% 35V
C205 1-126-947-11 ELECT 47uF 20% 35V
C206 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C207 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C208 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C209 1-126-935-11 ELECT 470uF 20% 6.3V
C210 1-104-665-11 ELECT 100uF 20% 10V
C211 1-104-665-11 ELECT 100uF 20% 10V
C212 1-126-933-11 ELECT 100uF 20% 16V
C213 1-115-419-11 CERAMIC CHIP 3300PF 5% 25V
C214 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C217 1-104-666-11 ELECT 220uF 20% 25V
C218 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C220 1-126-965-11 ELECT 22uF 20% 50V
C221 1-115-419-11 CERAMIC CHIP 3300PF 5% 25V
C222 1-115-419-11 CERAMIC CHIP 3300PF 5% 25V
C223 1-104-665-11 ELECT 100uF 20% 10V
C224 1-104-665-11 ELECT 100uF 20% 10V
C225 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C227 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C228 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C229 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C231 1-126-965-11 ELECT 22uF 20% 50V
C236 1-165-590-11 PETE FILM 0.0039uF 100V
C237 1-165-590-11 PETE FILM 0.0039uF 100V
C245 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C247 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C248 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C249 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C252 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C401 1-126-947-11 ELECT 47uF 20% 35V
C402 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C404 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C405 1-126-947-11 ELECT 47uF 20% 35V
C406 1-126-935-11 ELECT 470uF 20% 6.3V
C407 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C408 1-104-665-11 ELECT 100uF 20% 10V
To Next Page
