Sony RCD-W1 - Power Board and Deck Assemblies Removal; Power Board Removal; Deck Assemblies Removal

12
RCD-W1
3-7. CDP DECK ASSY (DECK A), CD-R DECK ASSY (DECK B)
6 Two screws (special)
2 Two screws (special)
5 CDP deck assy (deck A)
3 Two screws (special)
1 Wire (flat type)(PN605)
7 Two screws (special)
9
4
8
CD-R deck assy (deck B
)
3-6. POWER BOARD
3
4
Two screws (special
)
5 POWER board
2 Two screws (special)
1 Connector (PN601)
