Sony RCD-W1 - 2 General

8
RCD-W1
SECTION 2
GENERAL
1 Power button
2 OPEN/CLOSE A button (DECK A)
3 . AMS button (DECK A)
4 > AMS button (DECK A)
5 . AMS button (DECK B)
6 > AMS button (DECK B)
7 OPEN/CLOSE A button (DECK B)
8 H button (DECK B)
9 z REC button
q; REC LEVEL knob (DECK B)
qa X button (DECK B)
qs x button (DECK B)
qd INPUT button (DECK B)
qf TIME button (DECK B)
FRONT PANEL
qg ERASE button (DECK B)
qh FINALIZE button (DECK B)
qj DISC tray (DECK B)
qk CD SYNCHRO HIGH button
ql CD SYNCHRO NORMAL button
w; DISC tray (DECK A)
wa
remote sensor
ws TIME button (DECK A)
wd RELAY button (DECK A)
wf x button (DECK A)
wg X button (DECK A)
wh PHONE jack
wj PHONE LEVEL knob
wk H button (DECK A)
LOCATION OF PARTS AND CONTROLS
wk
21 34 56 7
wj
wh
qj qgqh qd qsqf
wa w; qlqkwd wswfwg
8
9
0
qa
