Sony RCD-W1 - BD Board and CDP Mechanism Removal; BD Board (Deck A) Removal; CDP Mechanism Assy (Deck A) Removal

13
RCD-W1
3-8. BD BOARD (DECK A)
3-9. CDP MECHANISM ASSY (DECK A)
1 Screw (1.7X6)
3 Clamp holder assy
7
2
8
A
5
Two screws
9 CDP mechanism ass
y
4 Push out the disc tray by pushing the
Up/Down guide un the drrow
A direction.
6 Disc tray
Up/Down guide
Main base
Bottom view
1 Three claws
3
6
Connector (PN609)
5 Wire (flat type) (PN401)
2 Wire (flat type) (PN301)
4 Wire (flat type) (PN201
)
BD board
