Sony RCD-W1 - Spindle Motor, Pick-Up Block, and BD-R Board Removal; Spindle Motor & Pick-Up Block Removal (Deck A); BD-R Board (Deck B) Removal

14
RCD-W1
3-11. BD-R BOARD (DECK B)
3 Wire (fiat type) (CN401)
4 Wire (fiat type) (CN501)
7
6
BD-R board
5 Wire (flat type) (CN502)
2 Connector (CN701)
1 Three claws
3-10. SPINDLE MOTOR ASSY, PICK-UP BLOCK (DECK A)
5 Screw (1.7X5)
3 Screw (1.7X5)
4 Shaft L
1 Three screws (2X6)
2
7
Spindle motor assy
6 Shaft R
8 Pick-up bloc
k
