Sony RCD-W1 - Electrical Parts List - BD-R and FL Boards (Continued); BD-R and FL Boards Parts List (Continued)

73
RCD-W1
IC304 8-759-300-71 IC BU4053BCF
IC306 6-700-346-01 IC CS8420-CSR
IC307 8-759-300-71 IC BU4053BCF
IC310 8-759-031-84 IC TC7S04F
IC401 8-752-097-31 IC CXA2551AR
IC403 8-759-058-45 IC NJM3403AV
IC404 8-759-338-95 IC NJM2903V(TE2)
IC405 8-759-387-26 IC BU4052BCFV-E2
IC406 8-759-545-66 IC NJM3414M
IC407 8-759-575-32 IC NC7SZ66P5X
IC409 8-759-635-27 IC M62352GP-75E
IC411 8-759-058-43 IC NJM3404AV
IC412 8-759-082-58 IC TC7W08FU(TE12R)
IC413 8-759-350-97 IC EL2245CS
IC414 8-759-575-32 IC NC7SZ66P5X
IC501 8-759-679-08 IC BA5983FM
IC502 8-759-536-49 IC BA5925FV-E2
IC508 8-759-448-71 IC BU4053BCFV-E2
IC509 8-759-058-43 IC NJM3404AV
IC510 8-759-588-60 IC BA6664FM-E2
IC511 8-759-697-62 IC NJM7808DL1A(TE1)
IC512 8-759-697-62 IC NJM7808DL1A(TE1)
IC514 8-759-545-66 IC NJM3414M
IC601 6-700-341-01 IC CST0100C
IC701 6-800-235-01 IC HD64F3062AFBL-CDR
IC702 8-759-466-52 IC CAT93C86S-LE10
< COIL >
L103 1-400-090-21 INDUCTOR 0uH
L202 1-412-058-11 INDUCTOR CHIP 10uH
L301 1-400-090-21 INDUCTOR 0uH
L302 1-412-058-11 INDUCTOR CHIP 10uH
L306 1-412-058-11 INDUCTOR CHIP 10uH
L308 1-412-058-11 INDUCTOR CHIP 10uH
L401 1-412-058-11 INDUCTOR CHIP 10uH
L402 1-412-058-11 INDUCTOR CHIP 10uH
L403 1-412-058-11 INDUCTOR CHIP 10uH
L701 1-412-058-11 INDUCTOR CHIP 10uH
< CONNECTOR >
PN105 1-815-765-11 SOCKET, CONNECTOR 6P
PN201 1-815-765-11 SOCKET, CONNECTOR 6P
PN605 1-784-383-21 CONNECTOR, FFC/FPC 26P
< TRANSISTOR >
Q401 1-801-806-11 TRANSISTOR DTC144EKA
Q402 1-801-806-11 TRANSISTOR DTC144EKA
Q403 1-801-806-11 TRANSISTOR DTC144EKA
Q404 1-801-806-11 TRANSISTOR DTC144EKA
Q405 1-801-806-11 TRANSISTOR DTC144EKA
< RESISTOR >
R101 1-216-838-11 METAL CHIP 27K 5% 1/16W
R102 1-216-844-11 METAL CHIP 82K 5% 1/16W
R103 1-216-833-11 METAL CHIP 10K 5% 1/16W
R104 1-216-864-11 METAL CHIP 0 5% 1/16W
R219 1-216-833-11 METAL CHIP 10K 5% 1/16W
R220 1-216-833-11 METAL CHIP 10K 5% 1/16W
R221 1-216-833-11 METAL CHIP 10K 5% 1/16W
R227 1-216-864-11 METAL CHIP 0 5% 1/16W
R228 1-216-812-11 METAL CHIP 180 5% 1/16W
R229 1-216-809-11 METAL CHIP 100 5% 1/16W
R230 1-216-809-11 METAL CHIP 100 5% 1/16W
R231 1-414-229-11 FERRITE 0UH
R234 1-216-835-11 METAL CHIP 15K 5% 1/16W
R235 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R236 1-216-821-11 METAL CHIP 1K 5% 1/16W
R237 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R238 1-216-833-11 METAL CHIP 10K 5% 1/16W
R239 1-216-813-11 METAL CHIP 220 5% 1/16W
R240 1-216-839-11 METAL CHIP 33K 5% 1/16W
R241 1-216-813-11 METAL CHIP 220 5% 1/16W
R245 1-216-813-11 METAL CHIP 220 5% 1/16W
R250 1-216-813-11 METAL CHIP 220 5% 1/16W
R251 1-216-813-11 METAL CHIP 220 5% 1/16W
R252 1-216-813-11 METAL CHIP 220 5% 1/16W
R253 1-216-813-11 METAL CHIP 220 5% 1/16W
R254 1-216-813-11 METAL CHIP 220 5% 1/16W
R255 1-216-813-11 METAL CHIP 220 5% 1/16W
R256 1-216-813-11 METAL CHIP 220 5% 1/16W
R257 1-216-813-11 METAL CHIP 220 5% 1/16W
R259 1-216-841-11 METAL CHIP 47K 5% 1/16W
R260 1-216-835-11 METAL CHIP 15K 5% 1/16W
R261 1-216-864-11 METAL CHIP 0 5% 1/16W
R262 1-216-864-11 METAL CHIP 0 5% 1/16W
R263 1-216-864-11 METAL CHIP 0 5% 1/16W
R264 1-216-864-11 METAL CHIP 0 5% 1/16W
R265 1-216-864-11 METAL CHIP 0 5% 1/16W
R266 1-216-864-11 METAL CHIP 0 5% 1/16W
R267 1-216-864-11 METAL CHIP 0 5% 1/16W
R268 1-216-864-11 METAL CHIP 0 5% 1/16W
R269 1-216-864-11 METAL CHIP 0 5% 1/16W
R270 1-164-156-11 CERAMIC CHIP 0.1uF 25V
R305 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
R306 1-216-813-11 METAL CHIP 220 5% 1/16W
R307 1-216-813-11 METAL CHIP 220 5% 1/16W
R308 1-216-813-11 METAL CHIP 220 5% 1/16W
R310 1-216-817-11 METAL CHIP 470 5% 1/16W
R320 1-216-833-11 METAL CHIP 10K 5% 1/16W
R322 1-216-813-11 METAL CHIP 220 5% 1/16W
R323 1-216-816-11 METAL CHIP 390 5% 1/16W
R325 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
R327 1-216-833-11 METAL CHIP 10K 5% 1/16W
R335 1-216-817-11 METAL CHIP 470 5% 1/16W
R336 1-216-818-11 METAL CHIP 560 5% 1/16W
R337 1-216-833-11 METAL CHIP 10K 5% 1/16W
R355 1-216-841-11 METAL CHIP 47K 5% 1/16W
R364 1-216-813-11 METAL CHIP 220 5% 1/16W
R365 1-216-813-11 METAL CHIP 220 5% 1/16W
R366 1-216-815-11 METAL CHIP 330 5% 1/16W
R367 1-216-821-11 METAL CHIP 1K 5% 1/16W
R368 1-216-809-11 METAL CHIP 100 5% 1/16W
R369 1-216-809-11 METAL CHIP 100 5% 1/16W
R370 1-216-809-11 METAL CHIP 100 5% 1/16W
R371 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R373 1-216-813-11 METAL CHIP 220 5% 1/16W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BD-R
