RCD-W1
< IC >
IC801 6-800-228-01 IC uPD780232GC-LG1
IC802 8-759-971-11 IC KIA7042P-TP
< RESISTOR >
R803 1-247-843-11 CARBON 3.3K 5% 1/4W
R804 1-249-424-11 CARBON 3.9K 5% 1/4W F
R807 1-249-420-11 CARBON 1.8K 5% 1/4W F
R808 1-249-422-11 CARBON 2.7K 5% 1/4W F
R809 1-247-843-11 CARBON 3.3K 5% 1/4W
R810 1-249-424-11 CARBON 3.9K 5% 1/4W F
R811 1-249-426-11 CARBON 5.6K 5% 1/4W
R812 1-249-428-11 CARBON 8.2K 5% 1/4W F
R813 1-249-420-11 CARBON 1.8K 5% 1/4W F
R814 1-249-422-11 CARBON 2.7K 5% 1/4W F
R815 1-247-843-11 CARBON 3.3K 5% 1/4W
R816 1-249-424-11 CARBON 3.9K 5% 1/4W F
R817 1-249-426-11 CARBON 5.6K 5% 1/4W
R818 1-249-428-11 CARBON 8.2K 5% 1/4W F
R819 1-249-431-11 CARBON 15K 5% 1/4W
R820 1-249-432-11 CARBON 18K 5% 1/4W
R821 1-249-432-11 CARBON 18K 5% 1/4W
R822 1-249-432-11 CARBON 18K 5% 1/4W
R833 1-247-807-31 CARBON 100 5% 1/4W
R834 1-247-843-11 CARBON 3.3K 5% 1/4W
R841 1-249-425-11 CARBON 4.7K 5% 1/4W F
R842 1-249-417-11 CARBON 1K 5% 1/4W F
R843 1-249-417-11 CARBON 1K 5% 1/4W F
R844 1-249-417-11 CARBON 1K 5% 1/4W F
R845 1-249-417-11 CARBON 1K 5% 1/4W F
R846 1-249-425-11 CARBON 4.7K 5% 1/4W F
R847 1-249-437-11 CARBON 47K 5% 1/4W
R848 1-249-437-11 CARBON 47K 5% 1/4W
R849 1-249-437-11 CARBON 47K 5% 1/4W
R850 1-249-437-11 CARBON 47K 5% 1/4W
R851 1-249-437-11 CARBON 47K 5% 1/4W
< INFRARED RECEIVER >
RMC801 8-749-016-29 IC RPM6938
< SWITCH >
SW803 1-762-875-21 SWITCH, KEYBOARD (AMS .)
SW804 1-762-875-21 SWITCH, KEYBOARD (AMS > )
SW808 1-762-875-21 SWITCH, KEYBOARD (CD SYNCHRO HIGH)
SW810 1-762-875-21 SWITCH, KEYBOARD (INPUT)
SW811 1-762-875-21 SWITCH, KEYBOARD (CD SYNCHRO NORMAL)
SW812 1-762-875-21 SWITCH, KEYBOARD (ERASE)
SW813 1-762-875-21 SWITCH, KEYBOARD (FINALIZE)
SW814 1-762-875-21 SWITCH, KEYBOARD (TIME)
SW815 1-762-875-21 SWITCH, KEYBOARD (OPEN/CLOSE A )
SW816 1-762-875-21 SWITCH, KEYBOARD (TIME)
SW817 1-762-875-21 SWITCH, KEYBOARD (AMS .)
SW818 1-762-875-21 SWITCH, KEYBOARD (AMS > )
SW819 1-762-875-21 SWITCH, KEYBOARD (RELAY)
SW820 1-762-875-21 SWITCH, KEYBOARD ( X )
SW821 1-762-875-21 SWITCH, KEYBOARD ( G )
SW822 1-762-875-21 SWITCH, KEYBOARD ( x )
< VIBRATOR >
X801 1-795-348-11 VIBRATOR, CRYSTAL (5MHz)
******************************************************
A-4726-177-A HP BOARD, COMPLETE
*****************
< JACK >
JK802 1-815-702-11 JACK (LARGE TYPE) (PHONES)
< CONNECTOR >
* PN804 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
0 PN902 1-815-703-11 PIN, CONNECTOR 2P
< SWITCH >
0 PW801 1-771-757-12 SWITCH, PUSH (1 KEY) (POWER)
< VARIABLE RESISTOR >
VR801 1-227-425-11 RES, VAR 50K/50K (PHONE LEVEL)
******************************************************
*
A-4727-517-A POWER BOARD, COMPLETE (E,MX)
* A-4735-112-A POWER BOARD, COMPLETE (US,CND)
*****************************
Note: The parts not described here are not supplied for service.
< CAPACITOR >
0 C903 1-165-878-11 ELECT 150uF 20% 250V
(US,CND)
0 C903 1-165-879-11 ELECT 100uF 20% 400V
(E,MX)
< COIL >
0 BC901 1-400-104-11 INDUCTOR 0UH
< BRIDGE DIODE >
0 BD901 8-719-510-06 DIODE S1WB60
< DIODE >
0 D902 8-719-085-16 DIODE EU01W
D906 8-719-085-15 DIODE RU3YXLF-C1
D907 8-719-085-16 DIODE EU01W
D908 8-719-085-16 DIODE EU01W
D909 8-719-085-17 DIODE B10A45V1
D910 8-719-085-16 DIODE EU01W
D920 8-719-085-16 DIODE EU01W
< FUSE >
0 F901 1-576-533-11 FUSE T1.6A 250V
< IC >
0 IC901 6-700-520-01 IC STR-G6153T
0 IC902 6-700-521-01 IC PS2561-1-V
IC904 6-700-522-01 IC KIA431
IC905 8-759-189-48 IC KA78R12TU
IC906 6-700-523-01 IC KA7912
IC907 8-759-347-19 IC KIA7812PI
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FL HP
POWER
