Sony RCD-W3 Service Manual

22
RCD-W3
– BD-R SECTION –
– PANEL SECTION –
3
1
2
6
5
IC301 tj (TE)
IC301 ia (RRF IN)
IC301 tk (FE)
IC502 qd
(ISCLK)
IC502 qs (ILRCK)
3.2 Vp-p
21 µ sec
0.8 Vp-p
0.2V/div
0.5
µ sec/div
9
IC403 qg (RF AC)
1.6 Vp-p
0.5V/div
0.5
µ sec/div
0.1V/div
5msec/div
0.1 Vp-p
0
IC403 qh (FE)
0.1V/div
5msec/div
0.1 Vp-p
0.5V/div
5msec/div
1V/div
10
µ sec/div
1V/div
50nsec/div
0.5 Vp-p
qa
IC403 ql (TE_BAL)
0.5V/div
5msec/div
0.5 Vp-p
7
IC510 td (AD MCLK)
3.4 Vp-p
90nsec
33.86MHz
1V/div
20nsec/div
8
IC510 t; (MCLK IN)
1V/div
20nsec/div
4
IC207 rf (34MCLK)
1.8 Vp-p
29nsec
qs
IC407 yh (EXTAL)
1.5 Vp-p
20MHz
0.5V/div
20nsec/div
3.2 Vp-p
0.44 µ sec
1V/div
0.2
µ sec/div
3.3 Vp-p
qd
IC408 2 (XOUT)
4.9 Vp-p
33.86MHz
1V/div
20nsec/div
qg
IC203 yh (EXTAL)
1.7 Vp-p
20MHz
0.5V/div
20nsec/div
qf
IC201 (XIN)
149
33.86MHz
1V/div
20nsec/div
3.3 Vp-p
5MHz
2V/div
0.1
µ sec/div
1
IC801 4 (X2)
5.3 Vp-p

Sony RCD-W3 Specifications

Power

power requirements	U.S.A. and Canada 120 V AC, 60 Hz
power requirements other countries	110 – 240 V AC, 50/60 Hz
power consumption	20 W

Audio Specifications

frequency response	20 Hz – 20, 000 Hz (±0.5 dB)
signal-to-noise ratio	More than 100 dB
dynamic range	More than 95 dB

Inputs

analog in impedance	47 kilohms
rated input	330 mVrms
minimum input	125 mVrms

Outputs

analog out rated output	2 Vrms (at 50 kilohms)
load impedance	over 10 kilohms
phones	28 mW, 32 ohms

Weight and Dimensions

dimensions	430 × 108 × 368 mm
mass	4.6 kg
