Sony RCD-W3 Service Manual

57
RCD-W3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AUDIO
< TRANSISTOR >
Q701 8-729-037-16 TRANSISTOR KRA103M-AT
Q702 8-729-016-64 TRANSISTOR KTD1302
Q703 8-729-016-64 TRANSISTOR KTD1302
Q704 8-729-016-64 TRANSISTOR KTD1302
Q705 8-729-037-16 TRANSISTOR KRA103M-AT
Q706 8-729-036-89 TRANSISTOR KTC3198GR-A
Q709 8-729-036-89 TRANSISTOR KTC3198GR-A
Q710 8-729-036-89 TRANSISTOR KTC3198GR-A
Q711 8-729-016-64 TRANSISTOR KTD1302
Q712 8-729-016-64 TRANSISTOR KTD1302
< RESISTOR >
R701 1-216-049-11 RES-CHIP 1K 5% 1/10W
R702 1-216-654-11 METAL CHIP 1.3K 0.5% 1/10W
R703 1-216-025-11 RES-CHIP 100 5% 1/10W
R704 1-216-025-11 RES-CHIP 100 5% 1/10W
R705 1-216-025-11 RES-CHIP 100 5% 1/10W
R706 1-216-041-00 METAL CHIP 470 5% 1/10W
R707 1-216-041-00 METAL CHIP 470 5% 1/10W
R708 1-216-049-11 RES-CHIP 1K 5% 1/10W
R70A 1-216-025-11 RES-CHIP 100 5% 1/10W
R70B 1-216-025-11 RES-CHIP 100 5% 1/10W
R70C 1-216-025-11 RES-CHIP 100 5% 1/10W
R70D 1-216-025-11 RES-CHIP 100 5% 1/10W
R70E 1-216-049-11 RES-CHIP 1K 5% 1/10W
R70F 1-216-025-11 RES-CHIP 100 5% 1/10W
R70G 1-216-025-11 RES-CHIP 100 5% 1/10W
R711 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R712 1-216-089-91 RES-CHIP 47K 5% 1/10W
R713 1-216-089-91 RES-CHIP 47K 5% 1/10W
R714 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R715 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R716 1-216-073-91 RES-CHIP 10K 5% 1/10W
R717 1-216-295-91 SHORT CHIP 0
R718 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R719 1-216-066-00 METAL CHIP 5.1K 5% 1/10W
R720 1-216-083-00 METAL CHIP 27K 5% 1/10W
R733 1-216-049-11 RES-CHIP 1K 5% 1/10W
R734 1-216-049-11 RES-CHIP 1K 5% 1/10W
R735 1-216-009-91 RES-CHIP 22 5% 1/10W
R736 1-216-009-91 RES-CHIP 22 5% 1/10W
R737 1-216-049-11 RES-CHIP 1K 5% 1/10W
R738 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R740 1-216-049-11 RES-CHIP 1K 5% 1/10W
R741 1-216-083-00 METAL CHIP 27K 5% 1/10W
R742 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R743 1-216-009-91 RES-CHIP 22 5% 1/10W
R744 1-216-009-91 RES-CHIP 22 5% 1/10W
R745 1-216-089-91 RES-CHIP 47K 5% 1/10W
R746 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R749 1-216-089-91 RES-CHIP 47K 5% 1/10W
R750 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R752 1-216-089-91 RES-CHIP 47K 5% 1/10W
R753 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R763 1-216-049-11 RES-CHIP 1K 5% 1/10W
R764 1-216-049-11 RES-CHIP 1K 5% 1/10W
R766 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R768 1-216-654-11 METAL CHIP 1.3K 0.5% 1/10W
R770 1-216-066-00 METAL CHIP 5.1K 5% 1/10W
R771 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R772 1-216-049-11 RES-CHIP 1K 5% 1/10W
R773 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R774 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R775 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R776 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R777 1-216-009-91 RES-CHIP 22 5% 1/10W
R778 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R779 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R781 1-216-043-91 RES-CHIP 560 5% 1/10W
R782 1-216-043-91 RES-CHIP 560 5% 1/10W
R783 1-216-097-11 RES-CHIP 100K 5% 1/10W
R784 1-216-097-11 RES-CHIP 100K 5% 1/10W
R785 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R786 1-216-009-91 RES-CHIP 22 5% 1/10W
R788 1-216-049-11 RES-CHIP 1K 5% 1/10W
R789 1-216-049-11 RES-CHIP 1K 5% 1/10W
R790 1-216-073-91 RES-CHIP 10K 5% 1/10W
R791 1-216-073-91 RES-CHIP 10K 5% 1/10W
R794 1-216-049-11 RES-CHIP 1K 5% 1/10W
R795 1-216-049-11 RES-CHIP 1K 5% 1/10W
R796 1-216-021-00 METAL CHIP 68 5% 1/10W
R797 1-216-021-00 METAL CHIP 68 5% 1/10W
R798 1-216-049-11 RES-CHIP 1K 5% 1/10W
R799 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R7V2 1-216-037-00 METAL CHIP 330 5% 1/10W
R7V3 1-216-037-00 METAL CHIP 330 5% 1/10W
R7V4 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R7V5 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
******************************************************
BD-P BOARD
**********
1-824-782-11 WIRE (FLAT TYPE) (22 CORE)
< CONNECTOR >
* PN4M5 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< SWITCH >
SW4M1 1-786-204-11 SWITCH, DETECTION (LOADING/OPEN)
******************************************************
A-4731-044-A BD-R BOARD, COMPLETE
******************
< CAPACITOR >
C201 1-124-779-00 ELECT CHIP 10uF 20% 16V
C202 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C208 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C209 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C210 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C211 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C212 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C213 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
BD-R
BD-P

Sony RCD-W3 Specifications

Power

power requirements	U.S.A. and Canada 120 V AC, 60 Hz
power requirements other countries	110 – 240 V AC, 50/60 Hz
power consumption	20 W

Audio Specifications

frequency response	20 Hz – 20, 000 Hz (±0.5 dB)
signal-to-noise ratio	More than 100 dB
dynamic range	More than 95 dB

Inputs

analog in impedance	47 kilohms
rated input	330 mVrms
minimum input	125 mVrms

Outputs

analog out rated output	2 Vrms (at 50 kilohms)
load impedance	over 10 kilohms
phones	28 mW, 32 ohms

Weight and Dimensions

dimensions	430 × 108 × 368 mm
mass	4.6 kg
