Sony RCD-W3 Service Manual

61
RCD-W3
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R249 1-216-805-11 METAL CHIP 47 5% 1/16W
R250 1-216-805-11 METAL CHIP 47 5% 1/16W
R251 1-216-805-11 METAL CHIP 47 5% 1/16W
R252 1-216-805-11 METAL CHIP 47 5% 1/16W
R253 1-216-805-11 METAL CHIP 47 5% 1/16W
R254 1-216-805-11 METAL CHIP 47 5% 1/16W
R255 1-216-805-11 METAL CHIP 47 5% 1/16W
R259 1-216-811-11 METAL CHIP 150 5% 1/16W
R260 1-216-845-11 METAL CHIP 100K 5% 1/16W
R261 1-216-809-11 METAL CHIP 100 5% 1/16W
R262 1-216-809-11 METAL CHIP 100 5% 1/16W
R263 1-216-809-11 METAL CHIP 100 5% 1/16W
R264 1-216-809-11 METAL CHIP 100 5% 1/16W
R265 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R266 1-216-833-11 METAL CHIP 10K 5% 1/16W
R267 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R268 1-216-813-11 METAL CHIP 220 5% 1/16W
R269 1-216-821-11 METAL CHIP 1K 5% 1/16W
R270 1-216-821-11 METAL CHIP 1K 5% 1/16W
R271 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R277 1-216-833-11 METAL CHIP 10K 5% 1/16W
R279 1-216-864-11 METAL CHIP 0 5% 1/16W
R280 1-216-805-11 METAL CHIP 47 5% 1/16W
R281 1-216-805-11 METAL CHIP 47 5% 1/16W
R283 1-216-805-11 METAL CHIP 47 5% 1/16W
R284 1-216-809-11 METAL CHIP 100 5% 1/16W
R285 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R286 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R287 1-216-821-11 METAL CHIP 1K 5% 1/16W
R288 1-216-817-11 METAL CHIP 470 5% 1/16W
R289 1-216-817-11 METAL CHIP 470 5% 1/16W
R290 1-216-805-11 METAL CHIP 47 5% 1/16W
R291 1-216-805-11 METAL CHIP 47 5% 1/16W
R292 1-216-833-11 METAL CHIP 10K 5% 1/16W
R293 1-216-833-11 METAL CHIP 10K 5% 1/16W
R294 1-216-833-11 METAL CHIP 10K 5% 1/16W
R295 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R296 1-216-833-11 METAL CHIP 10K 5% 1/16W
R2Q1 1-216-809-11 METAL CHIP 100 5% 1/16W
R2Q2 1-216-809-11 METAL CHIP 100 5% 1/16W
R301 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R302 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R303 1-216-817-11 METAL CHIP 470 5% 1/16W
R304 1-216-833-11 METAL CHIP 10K 5% 1/16W
R305 1-216-864-11 METAL CHIP 0 5% 1/16W
R306 1-216-819-11 METAL CHIP 680 5% 1/16W
R307 1-216-819-11 METAL CHIP 680 5% 1/16W
R308 1-216-841-11 METAL CHIP 47K 5% 1/16W
R313 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R314 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R315 1-216-835-11 METAL CHIP 15K 5% 1/16W
R316 1-216-835-11 METAL CHIP 15K 5% 1/16W
R317 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R318 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R319 1-216-801-11 METAL CHIP 22 5% 1/16W
R320 1-216-801-11 METAL CHIP 22 5% 1/16W
R321 1-216-801-11 METAL CHIP 22 5% 1/16W
R322 1-216-801-11 METAL CHIP 22 5% 1/16W
R323 1-216-839-11 METAL CHIP 33K 5% 1/16W
R324 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R325 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R326 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R327 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R328 1-216-833-11 METAL CHIP 10K 5% 1/16W
R329 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R330 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R331 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R332 1-216-813-11 METAL CHIP 220 5% 1/16W
R333 1-216-837-11 METAL CHIP 22K 5% 1/16W
R335 1-216-836-11 METAL CHIP 18K 5% 1/16W
R336 1-216-833-11 METAL CHIP 10K 5% 1/16W
R337 1-216-837-11 METAL CHIP 22K 5% 1/16W
R338 1-216-833-11 METAL CHIP 10K 5% 1/16W
R339 1-216-833-11 METAL CHIP 10K 5% 1/16W
R340 1-216-844-11 METAL CHIP 82K 5% 1/16W
R350 1-216-843-11 METAL CHIP 68K 5% 1/16W
R351 1-216-838-11 METAL CHIP 27K 5% 1/16W
R352 1-216-838-11 METAL CHIP 27K 5% 1/16W
R353 1-216-843-11 METAL CHIP 68K 5% 1/16W
R354 1-216-851-11 METAL CHIP 330K 5% 1/16W
R355 1-216-857-11 METAL CHIP 1M 5% 1/16W
R356 1-216-833-11 METAL CHIP 10K 5% 1/16W
R357 1-216-817-11 METAL CHIP 470 5% 1/16W
R358 1-216-833-11 METAL CHIP 10K 5% 1/16W
R359 1-216-821-11 METAL CHIP 1K 5% 1/16W
R360 1-216-809-11 METAL CHIP 100 5% 1/16W
R361 1-216-819-11 METAL CHIP 680 5% 1/16W
R362 1-216-819-11 METAL CHIP 680 5% 1/16W
R363 1-216-819-11 METAL CHIP 680 5% 1/16W
R364 1-216-819-11 METAL CHIP 680 5% 1/16W
R365 1-216-819-11 METAL CHIP 680 5% 1/16W
R368 1-216-864-11 METAL CHIP 0 5% 1/16W
R369 1-216-864-11 METAL CHIP 0 5% 1/16W
R370 1-216-864-11 METAL CHIP 0 5% 1/16W
R371 1-216-864-11 METAL CHIP 0 5% 1/16W
R372 1-216-864-11 METAL CHIP 0 5% 1/16W
R373 1-216-864-11 METAL CHIP 0 5% 1/16W
R374 1-216-850-11 METAL CHIP 270K 5% 1/16W
R375 1-216-833-11 METAL CHIP 10K 5% 1/16W
R376 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R377 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R388 1-216-839-11 METAL CHIP 33K 5% 1/16W
R389 1-216-839-11 METAL CHIP 33K 5% 1/16W
R390 1-216-833-11 METAL CHIP 10K 5% 1/16W
R391 1-216-837-11 METAL CHIP 22K 5% 1/16W
R392 1-216-864-11 METAL CHIP 0 5% 1/16W
R394 1-216-864-11 METAL CHIP 0 5% 1/16W
R396 1-216-835-11 METAL CHIP 15K 5% 1/16W
R397 1-216-850-11 METAL CHIP 270K 5% 1/16W
R398 1-216-837-11 METAL CHIP 22K 5% 1/16W
R399 1-216-835-11 METAL CHIP 15K 5% 1/16W
R3A1 1-216-864-11 METAL CHIP 0 5% 1/16W
R3A2 1-216-835-11 METAL CHIP 15K 5% 1/16W
R3A3 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R3A4 1-216-834-11 METAL CHIP 12K 5% 1/16W
BD-R

Sony RCD-W3 Specifications

Power

power requirements	U.S.A. and Canada 120 V AC, 60 Hz
power requirements other countries	110 – 240 V AC, 50/60 Hz
power consumption	20 W

Audio Specifications

frequency response	20 Hz – 20, 000 Hz (±0.5 dB)
signal-to-noise ratio	More than 100 dB
dynamic range	More than 95 dB

Inputs

analog in impedance	47 kilohms
rated input	330 mVrms
minimum input	125 mVrms

Outputs

analog out rated output	2 Vrms (at 50 kilohms)
load impedance	over 10 kilohms
phones	28 mW, 32 ohms

Weight and Dimensions

dimensions	430 × 108 × 368 mm
mass	4.6 kg
