Sony RCP-920 - Location and Function of Parts; Operation Panel

Location and Function of Parts
48
Location and Function of Parts
Operation Panel
IRIS
REMOTE CONTROL PANEL RCP-921
IRIS
MASTER
BLACK
CLOSE OPEN
SENS
COARSE
IRIS/MB
ACTIVE
EXT
D EXT
NET
WORK
RELATIVE AUTO
KNEE
OFF
DETAIL
OFF
CALL button
ALARM indicator
Master gain control block
Filter control block
SHUTTER control block
NETWORK indicator
Camera/CCU function ON/OFF buttons
Paint control block
AUTO SETUP block
White balance/black balance control block
CLOSE button
Iris/master black control block (page 54 and 55)
Iris/master black control block (pages 53 and 54)
RCP-920
RCP-921
Camera number/tally indication window
Control select block
Power and output signal select block
STANDARD button
OPT indicators
PANEL ACTIVE button
Expanded camera/CCU function ON/OFF buttons
Scene file control block
