Appendix
HXCU-100
4-140-418-12 (1)
License Declarations
The CCU teleprompter video circuit uses MPEG-2 technology.
MPEG-2 Video Patent Portfolio License
ANY USE OF THIS PRODUCT OTHER THAN CONSUMER
PERSONAL USE IN ANY MANNER THAT COMPLIES WITH
THE MPEG-2 STANDARD FOR ENCODING VIDEO
INFORMATION FOR PACKAGED MEDIA IS EXPRESSLY
PROHIBITED WITHOUT A LICENSE UNDER APPLICABLE
PATENTS IN THE MPEG-2 PATENT PORTFOLIO, WHICH
LICENSE IS AVAILABLE FROM MPEG LA, L.L.C., 250
STEELE STREET, SUITE 300, DENVER, COLORADO
80206.
“PACKAGED MEDIA” means any storage media storing
MPEG-2 video information such as DVD movie which are sold/
distributed to general consumers. Disc replicators or sellers of
the PACKAGED MEDIA need to obtain licenses for their own
business from MPEG LA. Please contact MPEG LA for any
further information. MPEG LA. L.L.C., 250 STEELE STREET,
SUITE 300, DENVER, COLORADO 80206
http://www.mpegla.com
Specifications
HXCU-100
RET1 HD SDI RET4 HD SDI RET3 VBS RET2 VBS
RET1 HD SDI RET4 SD SDI RET3 VBS RET2 VBS
RET1 SD SDI RET4 HD SDI RET3 VBS RET2 VBS
RET1 SD SDI RET4 SD SDI RET3 VBS RET2 VBS
RET3 HD SDI RET2 HD SDI RET1 VBS RET4 VBS
RET3 HD SDI RET2 SD SDI RET1 VBS RET4 VBS
RET3 SD SDI RET2 HD SDI RET1 VBS RET4 VBS
RET3 SD SDI RET2 SD SDI RET1 VBS RET4 VBS
RET3 HD SDI RET4 HD SDI RET1 VBS RET2 VBS
RET3 HD SDI RET4 SD SDI RET1 VBS RET2 VBS
RET3 SD SDI RET4 HD SDI RET1 VBS RET2 VBS
RET3 SD SDI RET4 SD SDI RET1 VBS RET2 VBS
General
Power supply AC 100 to 240 V, 50/60 Hz
Current consumption 4.5 A (max)
Peak inrush current (1) Power ON, current probe method: 43 A
(240 V)
(2) Hot switching inrush current, measured
in accordance with European standard
EN55103-1: 8 A (230 V)
Operating temperature 5 to 40 °C (41 to 104 °F)
Storage temperature −20 to +60 °C (−4 to +140 °F)
Weight Approx. 8.3 kg (18 lb 5 oz)
SDI 1/3 SDI 2/4 VBS 1/3 VBS 2/4 Input/output connectors
CAMERA Triax (1)
United States and Canada: Kings type
Other areas: Fischer type
INTERCOM XLR 5-pin (1)
INTERCOM/TALLY/
PGM
D-sub 25-pin, female (1)
• INCOM (PROD/ENG), 4W/RTS/CC,
0dBu
• TALLY (R, G)
• PGM 2 systems, –20/0/+4 dBu
REMOTE 8-pin multiconnector (1)
TRUNK D-sub 9-pin, female (1), RS-422A 1 system
LAN 8-pin (1)
Input connectors
AC IN (1), AC 100 to 240 V
SERIAL RETURN
INPUT
BNC type (2)
HD SDI: SMPTE 292M, 0.8 Vp-p, 75 Ω,
1.485/1.4835 Gbps bit rate
SD SDI: SMPTE 259M, 270 Mbps bit rate
VBS RETURN INPUT BNC type (2), 1.0 Vp-p, 75 Ω
REFERENCE INPUT BNC type (2), loop-through output
HD: SMPTE 274M, tri-level sync, 0.6 Vp-p,
75 Ω
SD: Black burst (NTSC: 0.286 Vp-p, 75 Ω;
PAL: 0.3 Vp-p, 75Ω)
PROMPTER INPUT BNC type (2), loop-through output, VBS
signal, 1.0 Vp-p, 75 Ω, 1 system
MIC REMOTE D-sub 15-pin, female (1)
(JAE DA-C1-J10 series recommended)
Output connectors
SDI OUT BNC type (2)
HD SDI: SMTPE 292M, 0.8 Vp-p, 75 Ω,
1.485/1.4835 Gbps bit rate
SD SDI: SMPTE 259M, 0.8 Vp-p, 75 Ω,
270 Mbps bit rate
HD SDI/SD SDI selectable
SDI OUT (MONITOR) BNC type (2)
HD SDI: SMTPE 292M, 0.8 Vp-p, 75 Ω,
1.485/1.4835 Gbps bit rate
SD SDI: SMPTE 259M, 0.8 Vp-p, 75 Ω,
270 Mbps bit rate
HD SDI/SD SDI selectable
Pr/R/R-Y, Y/G/Y,
Pb/B/B-Y
BNC type (3)
• HD component video
Y (100% white): 0.7 Vp-p
Pr/Pb (75% color bar): 0.7 Vp-p, 75 Ω
• HD RGB video
R/G/B (100% white): 0.7 Vp-p, 75 Ω
• SD RGB video
R/G/B (100% white): 0.7 Vp-p, 75 Ω
• SD component video
Y (100% white): 0.714 Vp-p
Pr/Pb (75% color bar): 0.756 Vp-p, 75 Ω
VBS OUT BNC type (2), VBS 1.0 Vp-p, 75 Ω
PIX OUT BNC type (1), VBS/R/G/B (VBS 1.0 Vp-p,
75 Ω)
To Next Page
