Status Display
HXCU-100
4-140-418-12 (1)
System status
The camera model name and signal format are displayed at
the top of the page (a “-” mark is displayed instead when a
camera is not connected).
Reference: Reference signal format and lock status
SDI-1/2: SDI OUTPUT 1/2 connector output format setting
SDI-3/4: SDI OUTPUT 3/4 connector output format setting
Component: Component signal connector output format
setting
Return1: Return 1 return signal format setting
Return2: Return 2 return signal format setting
Return3: Return 3 return signal format setting
Return4: Return 4 return signal format setting
CCU hardware diagnostics
The camera Auto Setup category, and the corresponding
setup item and status are displayed at the top of the page.
DPR: DPR board status
SDI: SDI board status
SY: SY board status
VIF: VIF board status
Front Panel: HKCU-FP1 CCU Control Panel status (displayed
only when the HKCU-FP1 CCU Control Panel is fitted)
Camera system diagnostics
Page 1
TRIAX Type: Triax transmission mode
TRIAX Cable: CCU triax cable connection status
TRIAX Comp.: Triax cable compensation mode selection
TRIAX Step: Triax cable compensation step (internal circuit
step display)
Fan Power: CCU power supply fan status
Timer: Elapsed time since power-on
CCU Power: CCU power supply type and status
SerialNo: CCU serial number
Page 2
CAMERA Cable: Camera cable connection status
CAMERA Data: Camera data transmission status
CAMERA Power: Camera power supply status
CAMERA Tone: Camera identification tone detection status
REMOTE Cable: Remote device cable connection status
REMOTE Data: Remote device data transmission status
REMOTE Power: Remote device power supply status
Page 3
Intercom CCU: CCU intercom selection
Intercom CAMERA CH1: Camera intercom channel 1
selection and microphone status
Intercom CAMERA CH2: Camera intercom channel 2
selection and microphone status
CAM MIC Gain: Camera microphone circuit control selection
CAM MIC CH1: Camera microphone channel 1 amplifier gain
CAM MIC CH2: Camera microphone channel 2 amplifier gain
Network diagnostics
Page 1
MacAddress: MAC address stored in CCU EEPROM
Auto Negotiation: Auto negotiation setting
Auto MDI/MDIX: Auto-MDIX setting
*System Status* 1/12
HXC-100 1080/59.94I
Reference:Free Lock
SDI-1/2 :1080/59.94I
SDI-3/4 :525/59.94I
Component:SD YCD
Return1 :1080/59.94I
Return2 :525/59.94I
Return3 :NTSC
Return4 :NTSC
*Diagnosis* 2/12
DPR :OK SDI :OK
SY :OK VIF :OK
Front Panel : OK
*System Diag 1/3* 3/12
TRIAX Type Digital
Cable Connect
Comp. Auto
Step 4
Fan Power OK
Timer 96H
CCU Power AC OK
SerialNo 100001
*System Diag 2/3* 4/12
CAMERA Cable Connect
Data OK
Power OK
Tone Detect
REMOTE Cable Connect
Data OK
Power OK
*System Diag 3/3* 5/12
Intercom
CCU Private
CAMERA CH1 ENG
MIC OFF
CH2 ENG
MIC OFF
CAM MIC Gain Local
CH1 60
dB
CH2 60
dB
*Network Diag 1/3* 6/12
MacAddress:000000-000000
Auto Negotiation: ON
Auto MDI/MDIX : ON
Connection Speed:100M
Duplex Mode :HALF
MDI/MDIX :MDIX
Link Status :OK
