Appendices
DIAGNOSIS Menu
This menu is only for viewing and no setting is made using this
menu.
Appendices
Precautions
Note on laser beams
Laser beams may damage the CCDs. If you shoot a scene that
includes a laser beam, be careful not to let a laser beam
become directed into the lens of the camera.
Do not subject to severe shocks
Damage to the case or internal components may result.
When finished using
Set the power switch to OFF.
Operation and storage environment
Store in a level place with air conditioning.
If the unit gets wet, make sure it is completely dry before
storage.
Avoid use or storage in the following places:
• Extremely hot or cold places
• Places with high humidity
• Places with strong vibration
• Near strong magnetic fields
• In places where it receives much direct sunlight, or near
heating equipment
Condensation
If you move the camera from a very cold place to a warm
place, or use it in a damp location, condensation may form on
the lens or inside the camera.
The camera has no built-in condensation indicator. If you find
condensation on the body or lens, switch the camera off and
wait for the condensation to disappear for about one hour.
Phenomena specific to CCD image sensors
The following phenomena that may appear in images are
specific to CCD (Charge Coupled Device) image sensors.
They do not indicate malfunctions.
White flecks
Although the CCD image sensors are produced with high-
precision technologies, fine white flecks may be generated on
the screen in rare cases, caused by cosmic rays.
This is related to the principle of CCD image sensors and is
not a malfunction.
The white flecks especially tend to be seen
• when operating at a high environmental temperature
• when you have raised the master gain (sensitivity)
The problem may be alleviated by automatic black balance
adjustment (see page 14).
Smear
When an extremely bright object, such as a strong spotlight or
flashlight, is being shot, vertical tails may be produced on the
screen, or the image may be distorted.
Page title
Page No.
Item Indication
<BOARD
STATUS>
D01
OHB OK, NG
DPR OK, NG
CD OK, NG
TX OK, NG
SY OK, NG
PS OK, NG
<PLD
VERSION>
D02
TG Vx.xxIT
AT Vx . x x
VDAP Vx.xx
VSOP Vx.xx
ASSIST Vx.xx
DEMUX Vx.xx
DEMAP Vx.xx
<ROM
VERSION>
D03 (U21)
AT Vx . x x
<SERIAL NO.>
D04
MODEL HXC-100
NO Serial No.
To Next Page
