Menu Configuration and Basic Operation
62
Primary
menu
Secondary
menu
Operation/
adjustment item
Settings Function Factory default
SETTING
(Continue)
VR REL
MODE SET
1)
WHITE Select from 1/1,
1/2, or 1/4
Sets variable range for white balance
in Relative mode
1/2
BLACK (FLARE) Select from 1/1,
1/2, or 1/4
Sets variable range for black (flare)
balance in Relative mode
1/2
DETAIL Select from 1/1,
1/2, or 1/4
Sets variable range for detail level in
Relative mode
1/2
B.GAM Select from 1/1,
1/2, or 1/4
Sets variable range for black gamma
in Relative mode
1/2
RCP No. SET RCP No. 1 to 24 Specifies System Number (RCP
Number) of RCP unit
3)
—
PREVIEW CONTACT ON/OFF Sets function for preview signal output
from EXT I/O connector on RCP
ON
CCU ON/OFF Sets function for preview signal output
from CCU
OFF
S-BUS ON/OFF Sets function for preview signal output
to S-BUS system
OFF
LED
BRIGHTNESS
SWITCH/LED 0 to 99 Sets lighted switch and LED
brightness
50
TALLY 0 to 99 Sets tally indication window
brightness
50
7SEGMENT 0 to 99 Sets brightness for 7-segment LED
display (MASTER GAIN/ND/CC
FILTER/IRIS/MASTER BLACK)
50
BUZZER
VOLUME
SWITCH 0 to 99 Sets volume of the sound emitted
when a switch on the RCP is pressed
50
CALL 0 to 99 Sets call volume of buzzer 50
TIME DATE XXXX / XX / XX Sets date —
TIME XX : XX Sets time —
TIME ZONE COUNTRY Sets time zone (GMT) London
SECURITY
MODE
MODE NORMAL/
ENGINEER
Specifies security level NORMAL
SET — Specifies mode —
CNS
SETTING
1)
CNS MODE LEGACY/
BRIDGE/MCS
Sets camera network system
connection mode
LEGACY: System connection using
conventional 700 protocol cable
BRIDGE: Mode for one-to-one
connections using the network
MCS: Mode for multi-camera systems
using the network
LEGACY
(Sub mode)
LEGACY: None
BRIDGE:
CONNECT
MCS: M/C
CONNECT:
PASSIVE/
ACTIVE/SEMI-AT
Sets submode for bridge mode
PASSIVE: Waits for connection
ACTIVE: Actively connects
SEMI-AT: Semi-automatic mode that
switches between PASSIVE/ACTIVE
based on device connected via 700
protocol
SEMI-AT
M/C:
CLIENT
Sets submode for multi-camera
system mode
CLIENT
MASTER IP
ADDR
xxx.xxx.xxx.xxx Sets master IP address of multi-
camera system mode
0.0.0.0
TARGET IP
ADDR
xxx.xxx.xxx.xxx Sets IP address for connection target
in bridge mode
0.0.0.0
