28
Menus
<SWITCH
ASSIGN1>
09 (U09)
GAIN
[L]:
–3, 0, 3, 6, 9, 12 dB
[M]:
–3, 0, 3, 6, 9, 12 dB
[H]:
–3, 0, 3, 6, 9, 12 dB
ASSIGNABLE 1 UC model:
OFF, RETURN1 SW,
RETURN2 SW, INCOM,
VF DETAIL, MIX VF,
5600K
, FAN MAX
CE model:
OFF, RETURN1 SW,
RETURN2 SW, ENG,
PROD, VF DETAIL, MIX
VF, 5600K
, FAN MAX
ASSIGNABLE 2 UC model:
OFF
, RETURN1 SW,
RETURN2 SW, INCOM,
VF DETAIL, MIX VF,
5600K, FAN MAX
CE model:
OFF
, RETURN1 SW,
RETURN2 SW, ENG,
PROD, VF DETAIL, MIX
VF, 5600K, FAN MAX
ASSIGNABLE
REAR
UC model:
OFF
, RETURN1 SW,
RETURN2 SW, INCOM,
VF DETAIL, MIX VF,
5600K, FAN MAX, VF
SCAN, CURSOR,
MARKER
CE model:
OFF
, RETURN1 SW,
RETURN2 SW, ENG,
PROD, VF DETAIL, MIX
VF, 5600K, FAN MAX, VF
SCAN, CURSOR,
MARKER
RE.ROTATION
Specify operation
mode of the
menu control
knob on the front.
STD
, RVS
STD: Clockwise rotation
moves the pointer
down or increases
values on the menu
screen.
RVS: Counterclockwise
rotation moves the
pointer down or
increases values on
the menu screen.
Page title
Page No.
Item Settings
<SWITCH
ASSIGN2>
10 (U10)
LENS VTR S/S
Assign a function
to the VTR
START/STOP
switch on the
mounted lens.
UC model:
OFF, RETURN1 SW,
RETURN2 SW
, INCOM
CE model:
OFF, RETURN1 SW,
RETURN2 SW
, ENG,
PROD
FRONT RET2
HANDLE SW1 UC model:
OFF, RETURN1 SW
,
RETURN2 SW, INCOM,
ZOOM(T)
CE model:
OFF, RETURN1 SW
,
RETURN2 SW, ENG,
PROD, ZOOM(T)
HANDLE SW2 UC model:
OFF, RETURN1 SW,
RETURN2 SW, INCOM
,
ZOOM(W)
CE model:
OFF, RETURN1 SW,
RETURN2 SW, ENG
,
PROD, ZOOM(W)
ZOOM SPEED 0 to 99 20
<HEAD SET>
11 (U13)
INTERCOM MIC DYNAMIC, CARBON,
MANUAL
LEVEL
–60,–40, –20 dB, (–60 dB)
Settings in ( ): With
DYNAMIC or
CARBON (cannot be
changed)
–6, 0, 6 dB
Input gain
POWER ON, OFF, (ON), (OFF)
Settings in ( ): With
DYNAMIC or
CARBON (cannot be
changed)
UNBAL ON
, OFF, (ON), (OFF)
Settings in ( ): With
CARBON (cannot be
changed)
<INTERCOM
LEVEL>
12 (U14)
SIDE TONE MU, 1 to 99, 50
<RECEIVE
SEL1>
13
INTERCOM
RECEIVE SELECT
SEPARATE, MIX
INTERCOM
UC model
only
- - -, LEFT, RIGHT, BOTH
ENG
CE model
only
- - -, LEFT
, RIGHT, BOTH
PROD
CE model
only
- - -, LEFT
, RIGHT, BOTH
PGM1 - - -, LEFT, RIGHT
, BOTH
PGM2 - - -, LEFT, RIGHT
, BOTH
TRACKER - - -, LEFT
, RIGHT, BOTH
Page title
Page No.
Item Settings
