Menus
<CALL/TALLY>
M07
Invalid when
no CCU
connected
CCU CALL - - -, ON
, OFF
CAM CALL - - -, ON, OFF
<OUTPUT
FORMAT>
M08 (U16)
CURRENT Displays the current
format.
ACTIVE LINE
Not displayed
when a CCU
connected
UC model:
1080 59.94i
, 1080 50i,
720 59.94P, 720 50P
CE model:
1080 59.94i, 1080 50i
,
720 59.94P, 720 50P
(When you change the
ACTIVE LINE setting, once
turn the camera off. The
camera will operate in the
selected mode when next
turned on.)
<DOWN
CONVERTER>
M09 (U19)
OUTPUT SIGNAL MAIN
, VF, RET
SETTING CAM, CCU
When a CCU is
connected: Either
CAM (settings made
with the camera) or
CCU (settings taken
from the linked CCU)
can be selected.
When CCU is
selected, the values
for the items shown
below are displayed in
parenthesis and
cannot be changed
with the camera.
When a CCU is not
connected: CCU
cannot be selected.
SD MATRIX ON, OFF, (ON)
, (OFF)
DETAIL ON, OFF, (ON)
, (OFF)
DTL LEVEL
–99 to 99 (–20)
H DTL FREQ
–99 to 99 (–20)
ASPECT SQ, EC, (SQ), (EC)
<TEST OUT>
M10 (U17)
OUTPUT SD-SYNC, VF, HD-SYNC,
VBS
(PWR SAVE) Displayed in POWER
SAVE mode only
VBS-OUT
CHARACTER ON, OFF
GAIN
–127 to 127 0
CHROMA
–127 to 127 0
SETUP
UC model
only
ON, OFF
Displayed when the
format is NTSC
HD SYNC-OUT
V-PHASE
–127 to 127 0
H-PHASE
–127 to 127 0
Page title
Page No.
Item Settings
<SDI OUT>
M11 (U18)
OUTPUT MAIN, VF, RET, SD-SDI
(PWR SAVE) Displayed in POWER
SAVE mode only
CHARACTER ON, OFF
Not displayed if
OUTPUT is set to VF
EMB AUDIO ON, OFF
(1-MIC1 2-MIC2)
(3-AES1 4-AES2)
Displayed when OUTPUT
is MAIN
(1-PGM1 2-PGM2)
(3-ENG 4-PROD)
Displayed when OUTPUT
is other than MAIN
<POWER
SAVE>
M12 (U11)
SDI OUT PWR SAVE
, ACTIVE
DOWN
CONVERTER
PWR SAVE, ACTIVE
PROMPTER PWR SAVE, ACTIVE
<TRUNK>
M13 (U20)
TRUNK ON
, OFF
<GENLOCK>
M14
Items other
than
REFERENCE
are displayed
only when no
CCU
connected.
REFERENCE Condition of
synchronisation, display
only
GENLOCK DISABLE
, ENABLE
STATUS Display only
FORMAT
PHASE
V
–1024 to 1023 0
HD H
–1700 to 1700 0
SD H
–1024 to 1023 0
<DATE>
M15
DATE/TIME yyyy/mm/dd
hh:mm
<BATTERY
ALARM>
M16
BEFORE END 11.5 V
to 17.0 V
END 11.0 V
to 11.5 V
Page title
Page No.
Item Settings
