2-2
2-3. FRONT PANEL SECTION
2-4. REAR PANEL
9
Rear panel
2
Connector
(CN202)
1
Flexible flat cable
(FMV-20: CN201)
3
Connector
(CN101)
4
Re-use clamp
5
Two screws
(B3)
6
Screw (B3)
7
Screw (B3)
8
Screw (B3)
1
Flexible flat cable
(FCI-1: CN303)
4
Claw
5
Claw
3
Two screws
(B3)
2
Two screws
(B3)
6
Front panel section
