2-8. ER-14 BOARD (AEP, UK)
2-9. TABLE ASS’Y
6
Harness
1
Connector
(CN001)
7
Table assembly
4
Two screws
(B3)
5
Two screws
(B3)
2
Flexible flat cable
(FMO-6: CN204)
3
Flexible flat cable
(FMM-42: CN203
)
2-7. AV-062 BOARD
3
AV-062 board
2
Six screws
(B3)(NC655P)
Five screws
(B3)(NC615)
1
Flexible flat cable
(FAE-10: CN101)
(AEP, UK)
3
ER-14 board
2
Two screw
s
(B3)
1
Flexible flat cable
(FAE-10: CN901)
