DVP-NC615/NC655P
4-5
WAVEFORMS
MB-103/AV-062/IF-091
60.6nsec
37nsec
40.7nsec
MB-103 BOARD
2
IC103 3,8
1
IC104 tf
4.4Vp-p
1.7Vp-p
3
IC103 9,q;
4.0Vp-p
4
IC103 qd,qg
29.5nsec
4.1Vp-p
H
H
H
H
AV-062 BOARD
2
IC102 ea
1
IC102 ed
640mVp-p
2.0Vp-p
3
IC102 wl
1.0Vp-p
4
IC102 wf
H
1.8Vp-p
5
IC102 ws
H
1.0Vp-p
6
IC102 w;
1.0Vp-p
124nsec
IF-091 BOARD
1
IC404 3
3.8Vp-p
