Sony RMT-B101A - Electrical Parts List: FL-180 Board; FL-180 Components

6-6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AU-258 FL-180
R140 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R141 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R142 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R143 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R144 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R145 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R146 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R149 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R150 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R153 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R154 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R155 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R156 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R157 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R158 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R161 1-216-845-11 METAL CHIP 100K 5% 1/10W
R162 1-216-845-11 METAL CHIP 100K 5% 1/10W
R163 1-216-845-11 METAL CHIP 100K 5% 1/10W
R165 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R166 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R167 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R168 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R169 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R170 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R171 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R173 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R175 1-216-864-11 SHORT CHIP 0
R176 1-216-864-11 SHORT CHIP 0
R177 1-216-864-11 SHORT CHIP 0
R178 1-216-809-11 METAL CHIP 100 5% 1/10W
A-1334-392-A FL-180 BOARD, COMPLETE
(Ref. No. 2000 Series)
**********************
< CAPACITOR >
C101 1-117-681-11 ELECT CHIP 100uF 20% 16V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C107 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C109 1-117-681-11 ELECT CHIP 100uF 20% 16V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C111 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C113 1-107-715-11 ELECT 22uF 20% 50V
C114 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C115 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C116 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C117 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C118 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C119 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C200 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C201 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C202 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C203 1-128-994-21 ELECT CHIP 47uF 20% 10V
C204 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C205 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C206 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C207 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C209 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C210 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
< CONNECTOR >
CN102 1-785-468-41 CONNECTOR, FFC/FPC 13P
CN200 1-774-730-21 PIN, CONNECTOR (PC BOARD) 3P
CN202 1-785-466-41 CONNECTOR, FFC/FPC 7P
< DIODE >
D103 6-501-476-01 DIODE NSSW008CT-T071 (LED Blue)
D104 6-501-476-01 DIODE NSSW008CT-T071 (LED Blue)
D107 8-719-988-61 DIODE 1SS355TE-17
D108 8-719-988-61 DIODE 1SS355TE-17
D109 8-719-988-61 DIODE 1SS355TE-17
D110 8-719-988-61 DIODE 1SS355TE-17
D111 8-719-036-94 DIODE RD5.6SB-T1
D201 8-719-988-61 DIODE 1SS355TE-17
< FUSE >
0F100 1-576-863-21 FUSE 0.5A 32V
< IC >
IC100 6-701-729-01 IC PT6315
IC201 6-703-591-01 IC BH6578FVM-TR
< COIL >
L100 1-414-743-21 INDUCTOR 47uH
< FLUORESCENT INDICATOR TUBE >
* ND100 1-519-974-11 INDICATOR TUBE, FLUORESCENT
< TRANSISTOR >
Q101 8-729-027-46 TRANSISTOR DTC114YKA-T146
Q106 6-551-382-01 TRANSISTOR RSS040P03FD5TB
Q107 8-729-901-88 TRANSISTOR 2SC2411K-CR
Q108 8-729-901-88 TRANSISTOR 2SC2411K-CR
< RESISTOR >
R100 1-216-833-11 METAL CHIP 10K 5% 1/10W
R102 1-216-814-11 METAL CHIP 270 5% 1/10W
R103 1-216-814-11 METAL CHIP 270 5% 1/10W
R105 1-216-805-11 METAL CHIP 47 5% 1/10W
R107 1-216-805-11 METAL CHIP 47 5% 1/10W
R108 1-216-805-11 METAL CHIP 47 5% 1/10W
R112 1-216-845-11 METAL CHIP 100K 5% 1/10W
R114 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R115 1-216-838-11 METAL CHIP 27K 5% 1/10W
R120 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R122 1-216-839-11 METAL CHIP 33K 5% 1/10W
R123 1-216-834-11 METAL CHIP 12K 5% 1/10W
R124 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R125 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R126 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R127 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R128 1-216-834-11 METAL CHIP 12K 5% 1/10W
R129 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R130 1-216-834-11 METAL CHIP 12K 5% 1/10W
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
