Sony RMT-B101A - Electrical Parts List: FR-276, IR-063, and Main Boards; FR-276 Components; IR-063 and Main Board Components

6-7
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R132 1-216-837-11 METAL CHIP 22K 5% 1/10W
R200 1-216-837-11 METAL CHIP 22K 5% 1/10W
R201 1-216-809-11 METAL CHIP 100 5% 1/10W
R202 1-216-839-11 METAL CHIP 33K 5% 1/10W
R203 1-216-836-11 METAL CHIP 18K 5% 1/10W
R204 1-216-837-11 METAL CHIP 22K 5% 1/10W
R206 1-216-845-11 METAL CHIP 100K 5% 1/10W
R207 1-216-833-11 METAL CHIP 10K 5% 1/10W
R208 1-216-837-11 METAL CHIP 22K 5% 1/10W
R210 1-216-809-11 METAL CHIP 100 5% 1/10W
R211 1-216-809-11 METAL CHIP 100 5% 1/10W
R212 1-216-821-11 METAL CHIP 1K 5% 1/10W
R213 1-216-864-11 SHORT CHIP 0
R214 1-216-864-11 SHORT CHIP 0
R215 1-216-837-11 METAL CHIP 22K 5% 1/10W
R216 1-216-837-11 METAL CHIP 22K 5% 1/10W
R217 1-216-809-11 METAL CHIP 100 5% 1/10W
R218 1-216-809-11 METAL CHIP 100 5% 1/10W
R219 1-216-809-11 METAL CHIP 100 5% 1/10W
R220 1-216-809-11 METAL CHIP 100 5% 1/10W
R221 1-216-809-11 METAL CHIP 100 5% 1/10W
R224 1-216-833-11 METAL CHIP 10K 5% 1/10W
R225 1-216-833-11 METAL CHIP 10K 5% 1/10W
R226 1-216-857-11 METAL CHIP 1M 5% 1/10W
R227 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S100 1-771-410-21 SWITCH, TACTIL (I/1)
< TRANSFORMER >
*0T100 1-445-303-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
A-1334-394-A FR-276 BOARD, COMPLETE
(Ref. No. 1000 Series)
**********************
< CAPACITOR >
C601 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C602 1-128-994-21 ELECT CHIP 47uF 20% 10V
C605 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
< CONNECTOR >
CN601 1-785-468-41 CONNECTOR, FFC/FPC 13P
< DIODE >
* D601 6-501-546-11 DIODE NSPW-310BST-A0S (FL OFF)
* D602 6-501-546-11 DIODE NSPW-310BST-A0S (HD)
* D603 6-501-546-11 DIODE NSPW-310BST-A0S (HDMI)
< IC >
IC601 6-600-392-01 IC GP1UM27XK0SF
< TRANSISTOR >
Q601 8-729-027-46 TRANSISTOR DTC114YKA-T146
Q602 8-729-027-46 TRANSISTOR DTC114YKA-T146
Q603 8-729-027-46 TRANSISTOR DTC114YKA-T146
Q611 8-729-028-27 TRANSISTOR 2SK2009 (TE85L)
< RESISTOR >
R601 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R602 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R603 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R610 1-216-805-11 METAL CHIP 47 5% 1/10W
R614 1-216-833-11 METAL CHIP 10K 5% 1/10W
R617 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R618 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R619 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R620 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R621 1-216-834-11 METAL CHIP 12K 5% 1/10W
R622 1-216-834-11 METAL CHIP 12K 5% 1/10W
R623 1-216-834-11 METAL CHIP 12K 5% 1/10W
R631 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S600 1-771-410-21 SWITCH, TACTIL (UP/DOWN)
S601 1-771-410-21 SWITCH, TACTIL (OPEN/CLOSE)
S602 1-771-410-21 SWITCH, TACTIL (.)
S603 1-771-410-21 SWITCH, TACTIL (>)
S604 1-771-410-21 SWITCH, TACTIL (X)
S605 1-771-410-21 SWITCH, TACTIL (x)
S606 1-771-410-21 SWITCH, TACTIL (H)
************************************************************
IR-063 BOARD
(Ref. No. 1000 Series)
***********
< CONNECTOR >
CN501 1-770-593-41 CONNECTOR, BOARD TO BOARD 5P
************************************************************
