Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks

R915 1-216-045-00 METAL CHIP 680 5% 1/10W

R916 1-216-055-00 METAL CHIP 1.8K 5% 1/10W

R917 1-216-055-00 METAL CHIP 1.8K 5% 1/10W

R918 1-216-021-00 METAL CHIP 68 5% 1/10W

R924 1-216-041-00 METAL CHIP 470 5% 1/10W

R926 1-216-041-00 METAL CHIP 470 5% 1/10W

R927 1-216-021-00 METAL CHIP 68 5% 1/10W

R928 1-216-021-00 METAL CHIP 68 5% 1/10W

R929 1-216-021-00 METAL CHIP 68 5% 1/10W

R939 1-216-017-91 RES-CHIP 47 5% 1/10W

R950 1-216-081-00 METAL CHIP 22K 5% 1/10W

R957 1-414-233-22 FERRITE 0UH

R958 1-414-233-22 FERRITE 0UH

************************************************************

FL-126 (E) BOARD, COMPLETE

(NS305:AEP1,AEP2,UK,RU/NS310/NS405/NS410)

**************************************

FL-126X BOARD, COMPLETE (NS315:MX,E)

***********************************

< CONNECTOR >

CN301 1-564-013-11 PIN, CONNECTOR 3P

< DIODE >

D301 6-500-176-01 DIODE EB3804X-TP-J555K

< RESISTOR >

R301 1-216-033-00 METAL CHIP 220 5% 1/10W

************************************************************

IF-89BM (U) BOARD, COMPLETE

(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/

NS315:US,CND,PX,AR,BR)

**************************************

IF-89BX (U) BOARD, COMPLETE

(NS315:MX1,MX2,E)

**************************************

IF-89BY (U) BOARD, COMPLETE (NS315:US4)

*************************************

IF-89SM (U) BOARD, COMPLETE (NS415)

*********************************

IF-89BR (E) BOARD, COMPLETE

(NS305:AEP1,AEP2,UK,RU/NS310)

**************************************

IF-89SR (E) BOARD, COMPLETE

(NS405,NS410)

**************************************

< CAPACITOR >

C401 1-126-947-11 ELECT 47uF 20% 16V

C402 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C404 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C405 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C407 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C408 1-119-774-11 ELECT 100uF 20% 16V

C409 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C411 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C414 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C415 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V

C416 1-104-665-11 ELECT 100uF 20% 25V

C417 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C418 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C420 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C421 1-128-551-11 ELECT 22uF 20% 25V

C423 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C424 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

C425 1-128-551-11 ELECT 22uF 20% 25V

C426 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V

C427 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

C428 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

< CONNECTOR >

CN401 1-506-478-11 PIN, CONNECTOR 13P

* CN405 1-785-530-11 PIN, CONNECTOR (PC BOARD) 10P

(NS305/NS310/NS315:US,CND,PX,AR,BR/NS405/NS410/NS415)

CN406 1-564-002-11 PIN, CONNECTOR 3P (NS415)

< DIODE >

D402 8-719-064-11 DIODE SPR-325MVW (NS405/NS410/NS415)

< IC >

IC403 6-701-875-01 IC LMS8117ADTX-1.8/NOPB

IC404 6-801-258-01 IC 86CK74AFG-3ND0(M

IC405 8-759-684-35 IC S-80830ANUP-EDT-T2

IC406 6-600-054-01 IC GP1UD24SYK

IC407 6-701-835-01 IC AN13990A-NML

< JUMPER RESISTOR >

JR401 1-216-295-91 SHORT 0

JR402 1-216-295-91 SHORT 0

JR403 1-216-295-91 SHORT 0
