Sony RMT-D141A - Custom Parental Control; Parental Control (limiting playback by children)

2-1
DVP-NS305/NS310/NS315/NS405/NS410/NS415
SECTION 2
DISASSEMBLY
NOTE: Follow the disassembly procedure in the numerical order given.
2-1. UPPER CASE
2-2. FRONT PANEL ASSEMBLY and FR SUPPORT
2 Tapping screws
1 Tapping screws
7 Tray cover
Chassis back
4 Upper case
5
6
3 Three screws
(SUMIEITE(B3)+BV)
1 Claw
3 Two claws
6 Two claws
5 Front panel assmbly
4 Three claws
2 Claw
8 FL-126 board
7 Connector
(FF-206, CN301, 3P)
9 Two screws
(SUMIEITE(B3)+BV)
0 FP support
