6-5. DRIVE MANUAL OPERATION
On the Test Mode Menu screen, select [2], and the manual opera-
tion menu will be displayed. For the manual operation, each servo
on/off control and adjustment can be executed manually.
In using the Manual Operation menu, take care of the following
points. These commands do not provide protection, thus requiring
correct operation. The sector address or time code field is dis-
played when a disc is loaded.
1. Set correctly the disc type to be used on the Disc Type
setting screen.
The Disc Type setting must be performed after a disc
was loaded.
The set Disc Type is cleared when the tray is opened.
2. After power ON, if the Manual Operation was selected,
first perform “Reset SLED TILT” by opening 1. Disc Type
screen.
3. In case of an alarm, immediately press the x button to
stop the servo operation, and turn the power OFF.
Basic operation (controllable from front panel or remote com-
mander)
[POWER] : Power OFF
x : Servo stop
A (Open/Close) : Stop+Eject/Loading
O : Return to Operation Menu or Test Mode Menu
> , . : Transition between sub modes of menu
[1] to [9], [0] : Selection of menu and items
Cursor [Q]/[q] : Increase/Decrease in manually adjusted value
0. Disc Check Memory
On this screen, the mirror time is measured and written to the
EEPROM to check the disc type. First, set a DVD SL disc and
press [1], then set a CD disc and press [2], and finally set a DVD
DL disc and press [3]. The measured mirror time is displayed re-
spectively.
The adjustment must be executed more than once after default
data were written.
From this screen, you can go to another mode by pressing >
or . key, but you cannot enter this mode from another mode.
You can enter this mode from the Operation Menu screen only.
1. Disc Type
On this screen, select the disc type. To select the disc type, press
the number of the loaded disc. The selected disc type is displayed
at the bottom. Selecting [1] automatically selects and displays the
disc type. In case of wrong display, retry “Disc Check Memory”.
Also, opening the tray causes the set disc type to be cleared. In
this case, set the disc type again after loading.
In performing manual operation, the disc type must be set.
## Drive Manual Operation ##
Operation Menu
1. Disc Type
2. Servo Control
3. Track/Layer Jump
4. Manual Adjustment
5. Auto Adjustment
6. Memory Check
0. Disc Check Memory
Exit: RETURN
Disc Check
1. SL Disc Check
2. CD Disc Check
3. DL Disc Check
0. Reset SLED TILT
Disc Type
1. Disc Type Auto Check
2. DVD SL 12cm
3. DVD DL 12cm
4. CD 12cm
5. SACD 12cm
6. DVD SL 8cm
7. DVD DL 8cm
8. CD 8cm
9. LCD 8cm
0. Reset SLED TILT
EMG. 00
To Next Page
