8-2. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
AV-61BM (G) BOARD, COMPLETE
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR)
**************************************
AV-61BM (U) BOARD, COMPLETE
(NS315:US,CND,PX,AR,BR)
**************************************
AV-61BR (E) BOARD, COMPLETE
(NS305:AEP1,AEP2,UK,RU/NS310)
**************************************
AV-61BX (U) BOARD, COMPLETE
(NS315:MX1,MX2,E)
**************************************
AV-61BY (U) BOARD, COMPLETE (NS315:US)
*************************************
AV-61SM (ME) BOARD, COMPLETE
(NS415:ME5,AUS)
**************************************
AV-61SM (U) BOARD, COMPLETE
(NS415:US,CND)
**************************************
AV-61SR (E) BOARD, COMPLETE
(NS405/NS410)
**************************************
< CAPACITOR >
C101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C102 1-126-947-11 ELECT 47uF 20% 16V
C109 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C110 1-126-947-11 ELECT 47uF 20% 16V
C111 1-126-947-11 ELECT 47uF 20% 16V
C112 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/
NS315/NS405/NS410/NS415)
C113 1-126-947-11 ELECT 47uF 20% 16V
C114 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C201 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C202 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C203 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
C204 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
C205 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
C206 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
C207 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C208 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C209 1-126-960-11 ELECT 1uF 20% 50V
C210 1-126-947-11 ELECT 47uF 20% 16V
C211 1-126-947-11 ELECT 47uF 20% 16V
C212 1-126-960-11 ELECT 1uF 20% 50V
(NS305:AEP1,AEP2,UK,RU/NS310/NS405/NS410)
C213 1-126-934-11 ELECT 220uF 20% 16V
C215 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
(NS305/NS310/NS405/NS410)
C216 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
(NS305/NS310/NS405/NS410)
C222 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C223 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C224 1-126-947-11 ELECT 47uF 20% 16V
C227 1-126-947-11 ELECT 47uF 20% 16V
C228 1-126-947-11 ELECT 47uF 20% 16V
C229 1-126-947-11 ELECT 47uF 20% 16V
C242 1-126-924-11 ELECT 330uF 20% 6.3V
C244 1-126-947-11 ELECT 47uF 20% 16V
< CONNECTOR >
CN102 1-815-149-11 CONNECTOR, FPC/FFC(1MM PIC)21P
(NS305:AEP1,AEP2,UK,RU/NS310/NS405/NS410)
* CN202 1-568-934-11 PIN, CONNECTOR 7P
< DIODE >
D101 8-719-073-01 DIODE MA111-(K8).S0 (NS415:US,CND)
D105 8-719-071-15 DIODE HZM6.8ZWA1TL
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/
NS315/NS405/NS410/NS415)
D106 8-719-071-15 DIODE HZM6.8ZWA1TL
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/
NS315/NS405/NS410/NS415)
D201 8-719-050-38 DIODE M1MA152WK-T1
D202 8-719-050-37 DIODE M1MA152WA-T1
D203 8-719-050-37 DIODE M1MA152WA-T1
(NS305:AEP1,AEP2,UK,RU/NS310/NS405/NS410)
D205 8-719-073-01 DIODE MA111-(K8).S0
D206 8-719-073-01 DIODE MA111-(K8).S0 (NS415:US,CND)
< IC >
IC102 8-759-826-46 IC LA73051-TLM
(NS305:AEP1,AEP2,UK,RU/NS310/NS405/NS410)
IC102 8-759-826-45 IC LA73050-TLM
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/NS315/NS415)
IC103 8-759-662-86 IC NJM79M05DL1A(TE2)
IC204 8-749-017-31 IC GP1FA550TZ (NS405/NS410/NS415)
IC204 8-749-923-04 IC TOTX178A (NS405/NS410/NS415)
IC201 6-701-937-01 IC TJM4558CDT
(NS305:AEP1,AEP2,UK,RU/NS310/NS405/NS410)
IC201 8-759-909-71 IC BA4558F-E2
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/NS315/NS415)
IC203 8-759-711-59 IC NJM78L05UA-TE1
AV-61
