8-7
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< JACK >
J102 1-816-668-11 JACK, PIN (3P) (NS315:US4)
J102 1-815-360-11 JACK, PIN 3P
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/NS315/NS415)
J103 1-816-663-11 CONNECTOR, S TERMINAL (4P) (NS315:US4)
J103 1-794-198-11 CONNECTOR, S TERMINAL
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/
NS315/NS405/NS410/NS415)
J104 1-815-362-21 JACK, PIN (6P) (NS415:US,CND)
J104 1-815-358-11 JACK, PIN (3P)
(NS305/NS310/NS315/NS405/NS410/NS415:ME5,AUS)
J201 1-793-446-21 JACK, PIN 1P
< JUMPER RESISTOR >
JR100 1-216-295-91 SHORT 0
JR101 1-216-295-91 SHORT 0
JR102 1-216-295-91 SHORT 0
JR104 1-216-295-91 SHORT 0
JR105 1-216-295-91 SHORT 0
JR106 1-216-295-91 SHORT 0
JR107 1-216-295-91 SHORT 0
JR108 1-216-295-91 SHORT 0
JR109 1-216-295-91 SHORT 0
JR110 1-216-295-91 SHORT 0
JR111 1-216-295-91 SHORT 0
JR112 1-216-295-91 SHORT 0
JR113 1-216-295-91 SHORT 0
< COIL >
L101 1-412-064-11 INDUCTOR 100uH
< TRANSISTOR >
Q104 8-729-421-19 TRANSISTOR MUN2213T1
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/
NS315/NS405/NS410/NS415)
Q105 8-729-424-08 TRANSISTOR MUN2111T1
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/
NS315/NS405/NS410/NS415)
Q106 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
(NS305:AEP1,AEP2,UK,RU/NS310/NS405/NS410)
Q201 8-729-049-31 TRANSISTOR 2SB710A-RTX
Q202 8-729-421-19 TRANSISTOR UN2213-TX
Q203 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
Q204 8-729-027-53 TRANSISTOR DTC124TKA-T146
Q205 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q206 8-729-421-19 TRANSISTOR UN2213-TX
(NS305:AEP1,AEP2,UK,RU/NS310/NS405/NS410)
Q207 6-550-137-01 TRANSISTOR SD1938(F)-ST(TX).SO
Q208 6-550-137-01 TRANSISTOR SD1938(F)-ST(TX).SO
Q209 8-729-027-53 TRANSISTOR DTC124TKA-T146
(NS305:AEP1,AEP2,UK,RU/NS310/NS405/NS410)
Q210 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
(NS305:AEP1,AEP2,UK,RU/NS310/NS405/NS410)
Q211 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
Q216 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
< RESISTOR >
R121 1-216-073-91 RES-CHIP 10K 5% 1/10W
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/
NS315/NS405/NS410/NS415)
R122 1-216-049-11 RES-CHIP 1K 5% 1/10W
(NS305:AEP1,AEP2,UK,RU/NS310/NS405/NS410)
R126 1-216-021-00 METAL CHIP 68 5% 1/10W
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/NS315/NS415)
R127 1-216-021-00 METAL CHIP 68 5% 1/10W
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/NS315/NS415)
R128 1-216-021-00 METAL CHIP 68 5% 1/10W
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/NS315/NS415)
R129 1-216-073-91 RES-CHIP 10K 5% 1/10W
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/
NS315/NS405/NS410/NS415)
R130 1-216-021-00 METAL CHIP 68 5% 1/10W
R133 1-216-021-00 METAL CHIP 68 5% 1/10W
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/
NS315/NS405/NS410/NS415)
R134 1-216-021-00 METAL CHIP 68 5% 1/10W
(NS305:ME2,EA,ME5,AUS,HK,SP,TW,KR/
NS315/NS405/NS410/NS415)
R153 1-215-860-11 METAL OXIDE 33 5% 1W
R154 1-216-295-91 SHORT 0
(NS305/NS310/NS315/NS405/NS410/NS415:ME5,AUS)
R201 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W
R202 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W
R203 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W
R204 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W
R205 1-208-800-11 METAL CHIP 5.6K 0.5% 1/10W
R206 1-208-800-11 METAL CHIP 5.6K 0.5% 1/10W
R207 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R208 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R209 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R210 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R211 1-208-800-11 METAL CHIP 5.6K 0.5% 1/10W
R212 1-208-800-11 METAL CHIP 5.6K 0.5% 1/10W
R213 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R214 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
(NS305:AEP1,AEP2,UK,RU/NS310/NS405/NS410)
R216 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R217 1-216-073-91 RES-CHIP 10K 5% 1/10W
R218 1-216-097-11 RES-CHIP 100K 5% 1/10W
R219 1-216-105-91 RES-CHIP 220K 5% 1/10W
R220 1-216-041-00 METAL CHIP 470 5% 1/10W
R221 1-216-073-91 RES-CHIP 10K 5% 1/10W
R222 1-216-073-91 RES-CHIP 10K 5% 1/10W
R224 1-216-073-91 RES-CHIP 10K 5% 1/10W
R225 1-216-089-91 RES-CHIP 47K 5% 1/10W
R226 1-216-041-00 METAL CHIP 470 5% 1/10W
R227 1-216-041-00 METAL CHIP 470 5% 1/10W
R228 1-216-073-91 RES-CHIP 10K 5% 1/10W
R229 1-216-089-91 RES-CHIP 47K 5% 1/10W
R230 1-216-089-91 RES-CHIP 47K 5% 1/10W
R231 1-216-073-91 RES-CHIP 10K 5% 1/10W
(NS305:AEP1,AEP2,UK,RU/NS310/NS405/NS410)
AV-61
