5-2
DVP-NS611HP/NS710H/NS710HP/NS717HP/NS718H/NS718HP/NS728H/NS728HP
Pin No. Pin name Type Function
44 RD3 InOut DRAM data 3
45 RD4 InOut DRAM data 4
46 RD5 InOut DRAM data 5
47 RD6 InOut DRAM data 6
48 RD7 InOut DRAM data 7
49 DQM0 InOut, PD Data Mask 0
50 RD15 InOut DRAM data 15
51 RD14 InOut DRAM data 14
52 DVDD18 Power 1.8V power pin for internal digital circuitry
53 RD13 InOut DRAM data 13
54 RD12 InOut DRAM data 12
55 RD11 InOut DRAM data 11
56 RD10 InOut DRAM data 10
57 RD9 InOut DRAM data 9
58 RD8 InOut DRAM data 8
59 DQM1 InOut, PD Data Mask 1
60 RCLK Output, PD DRAM clock
61 RA11 InOut, PD DRAM address 11
62 RA9 InOut, PD DRAM address 9
63 RA8 InOut, PD DRAM address 8
64 RA7 InOut, PD DRAM adress 7
65 RA6 InOut, PD DRAM address 6
66 RA5 InOut, PD DRAM address 5
67 RA4 InOut, PD DRAM address 4
68 XRWE InOut, PD DRAM Write enable (Active LOW)
69 XCAS InOut, PD DRAM Column address strobe (Active LOW)
70 XRAS InOut, PD DRAM Row address strobe (Active LOW)
71 DVDD33 Power 3.3V power pin for internal digital circuitry
72 BA0 InOut, PD DRAM bank address 0
73 BA1 InOut, PD DRAM bank address 1
74 RA10 InOut, PD DRAM address 10
75 RA0 InOut, PD DRAM address 0
76 RA1 InOut, PD DRAM address 1
77 RA2 InOut, PD DRAM address 2
78 RA3 InOut, PD DRAM address 3
79 DVDD18 Power 1.8V Power pin for internal digital circuitry
80 DDCSDA InOut, PD DDC IIC Data (For HDMI™)
81 DDCSCL InOut, PD DDC IIC Clock (For HDMI™)
82 EXT_RES Analog Input EXTERNAL RESISTOR FOR HDMI™ TX
83 AVDD33_VPLL Analog Power 3.3V VDD FOR HDMI™ TX
84 TXCN Analog Output Negative TX CLK
85 TXCP Analog Output Postive TX CLK
86 AVDD18_TX1 Analog Power 1.8V VDD FOR HDMI™ TX
87 TX0N Analog Output Negative TX CH0
88 TX0P Analog Output Postive TX CH0
89 AGND18_TX1 Ground 1.8V GND FOR HDMI™ TX
90 TX1N Analog Output Negative TX CH1
91 TX1P Analog Output Postive TX CH1
92 AVDD18_TX0 Power 1.8V VDD FOR HDMI™ TX
93 TX2N Analog Output Negative TX CH2
94 TX2P Analog Output Postive TX CH2
95 DACVDDC Power 3.3V Power pin for video DAC circuitry
96 VREF Analog Bandgap reference voltage
97 FS Analog Full scale adjustment
