Sony RMT-D187A - IF-163 Board Electrical Parts

8-4
NOTE:
• Due to standardization, replacements in the
parts list may be dierent from the parts
specied in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so
they may have some dierence from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-lm resistor.
METAL OXIDE: Metal oxide-lm resistor.
F: nonammable
• Not all of the parts for SWITCHING
REGULATOR are listed.
• Items marked * are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
• Abbreviation
AR : Argentina Model
AUS : Australia New Zealand Model
BR : Brazilian Model
CND : Canadian Model
E : Latin America Model
KS :
Saudi Arabia Mo
del
IN : India Model
IR : Iran Model
KR : Korea Model
MX : Mexican Model
8-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
RUS : Russian Model
SP : Singapore Model
TH : Thailand Model
TW : Taiwan Model
DVP-NS611HP/NS710H/NS710HP/NS717HP/NS718H/NS718HP/NS728H/NS728HP
The components identied by mark
or dotted line with mark are critical
for safety.
Replace only with part number
specied.
When indicating parts by reference
number, please include the board.
The components identied by mark
contain condential information.
Strictly follow the instructions
whenever the components are repaired
and/or replaced.
A-1660-278-A SERVI CE ASSY, IF-163
DVP-NS611HP, NS710H, NS710HP, NS717HP,
NS718H:CND,AUS,SP,TH,TW,KR
A-1660-791-A SERVI CE ASSY, IF-163
DVP-NS718H:AEP,UK
A-1663-516-A SERVI CE ASSY, IF-163
NS728H :AUS,NS728HP: EXCEPT RUS,BR
A-1660-782-A SERVI CE ASSY, IF-163
DVP-NS728HP:BR
A-1663-542-A SERVICE ASSY,IF-163
<CAPACITOR>
C401 1-162-970-91 CERAMIC CHIP 0. 01UF 10.00% 25V
C403 1-162-970-91 CERAMIC CHIP 0. 01UF 10.00% 25V
C404 1-162-970-91 CERAMIC CHIP 0. 01UF 10.00% 25V
C405 1-162-970-91 CERAMIC CHIP 0. 01UF 10.00% 25V
C406 1-162-964-91 CERAMIC CHIP 0. 001UF 10.00% 50V
C409 1-104-665-91 ELECT 100UF 20.00% 25V
C410 1-106-363-91 MYLAR 0.0068UF 5.00% 200V
C414 1-162-970-91 CERAMIC CHIP 0. 01UF 10.00% 25V
C416 1-127-715-91 CERAMIC CHIP 0. 22UF 10% 16V
C417 1-127-715-91 CERAMIC CHIP 0. 22UF 10% 16V
C419 1-128-131-91 ELECT 22UF 20.00% 50V
C421 1-126-786-91 ELECT 47UF 20% 16V
<CONNECTOR >
CN402 1-568-952-11 PIN, CONNECTOR 3P
<DIODE>
D402 6-501-193-01 DI ODE 1SS355WTE-17
D402 6-501-817-01 DIODE MA2J1110GLS0
D403 6-501-193-01 DI ODE 1SS355WTE-17
D403 6-501-817-01 DIODE MA2J1110GLS0
D406 6-501-726-01 DI ODE MAZ8047GMLS0
<IC>
IC404 6-808-635-01 IC TMP86CM74AFG-7D36
* IC406 6-600-626-01 IC GP1UW254GKC1
IC407 6-702-302-01 IC TK11133CSCL-G
IC408 6-704-114-01 IC S-80828CNUA-B8NT2G
<CH
IP CONDUCTOR>
JR401 1-216-295-91 SHORT CHIP 0
JR402 1-216-295-91 SHORT CHIP 0
JR403 1-216-295-91 SHORT CHIP 0
JR404 1-216-295-91 SHORT CHIP 0
JR405 1-216-295-91 SHORT CHIP 0
JR406 1-216-295-91 SHORT CHIP 0
JR407 1-216-295-91 SHORT CHIP 0
JR410 1-216-295-91 SHORT CHIP 0
JR415 1-216-295-91 SHORT CHIP 0
<COIL>
L401 1-408-982-81 I NDUCTOR 100UH
<FLUORESCENT>
ND402 1-519-930-11 VA CUUM FLUORESCENT DISPLAYS
<TRANSISTOR>
Q401 8-729-420-82 TRANSISTOR 2SD874A-R-TX
Q402 8-729-420-82 TRANSISTOR 2SD874A-R-TX
Q403 8-729-025-29 TRANSISTOR 2SK1828TE85L
<RESISTOR>
R401 1-216-833-91 METAL CHIP 10K 5 % 1/10W
R405 1-216-833-91 METAL CHIP 10K 5 % 1/10W
R406 1-216-809-91 METAL CHIP 100 5% 1/10W
R407 1-216-809-91 METAL CHIP 100 5% 1/10W
R408 1-216-809-91 METAL CHIP 100 5% 1/10W
R409 1-216-809-91 METAL CHIP 100 5% 1/10W
R412 1-216-833-91 METAL CHIP 10K 5 % 1/10W
R413 1-216-833-91 METAL CHIP 10K 5 % 1/10W
R416 1-216-833-91 METAL CHIP 10K 5 % 1/10W
R417 1-216-833-91 METAL CHIP 10K 5 % 1/10W
IF-163
DVP-NS728HP:RUS/NS728H:AEP,UK
**************************************************************
EA : Middle East Model
