6-5
DVP-NS611HP/NS710H/NS710HP/NS717HP/NS718H/NS718HP/NS728H/NS728HP
2-3-1. FLD All ON
2-3-1-1. Transition Keys in Self Check Mode
• Z key and x key on the main unit
• T key on the remote commander
2-3-1-2. Operation and display
In this mode, all segments of FLD turn ON.
• Example of FLD all ON
2-3-2. Main Unit Key Name Display and Key Code Display
2-3-2-1. Transition Keys in Self Check Mode
• Keys on the main unit except keys transited in Self Check Mode
2-3-2-2. Operation and Display
When a key on the main unit is pressed in the Self Check mode, the key code is displayed on the FLD. 'KEY FF' is displayed when
nothing is entered. Also, PLAY, PAUSE, REPEAT segments turn on when a communication error occurred.
• Key code display (at input of H key, key code: 0Ah)
• At input of faulty voltage
• When key is pressed double
To Next Page
