8-7
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DVP-NS611HP/NS710H/NS710HP/NS717HP/NS718H/NS718HP/NS728H/NS728HP
CN201 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN202 1-794-362-51 CONNECTOR, FFC/FPC 5P
* CN501 1-564-009-11 PIN, CONNECTOR 10P
<DIODE>
D311 6-501-675-01 DIODE HZM6.8ZMWATL-E
D312 6-501-675-01 DIODE HZM6.8ZMWATL-E
D313 6-501-675-01 DIODE HZM6.8ZMWATL-E
D314 6-501-675-01 DIODE HZM6.8ZMWATL-E
D401 6-501-817-01 DIODE MA2J1110GLS0
D403 6-501-726-01 DIODE MAZ8047GMLS0
<FERRITE>
FB106 1-469-324-21 FERRITE 0UH
FB108 1-469-324-21 FERRITE 0UH
FB111 1-469-670-21 FERRITE 0UH
FB112 1-469-670-21 FERRITE 0UH
FB115 1-400-382-21 FERRITE 0UH
FB116 1-414-226-21 FERRITE 0UH
FB123 1-400-382-21 FERRITE 0UH
FB124 1-469-670-21 FERRITE 0UH
FB129 1-469-112-21 FERRITE 0UH
FB132 1-400-382-21 FERRITE 0UH
FB133 1-400-382-21 FERRITE 0UH
FB134 1-400-382-21 FERRITE 0UH
FB135 1-400-382-21 FERRITE 0UH
FB501 1-469-324-21 FERRITE 0UH
FB504 1-469-324-21 FERRITE 0UH
<IC>
IC102 6-712-212-01 IC MX25L3205DM2I-12G (EXCEPT DVP-NS728HP:BR)
IC102 6-808-703-01 IC MX25L3205DM2I-12G-I3UH1XXXU (DVP-NS728HP:BR)
IC103 SEE NOTE ABOVE
IC105 6-702-302-01 IC TK11133CSCL-G
IC106 6-706-487-01 IC TC7SH08FU(T5RSOYJF)
IC107 6-702-302-01 IC TK11133CSCL-G
IC108 6-703-224-01 IC S-80828CNNB-B8NT2G
IC109 6-705-337-01 IC TK11150CSCL-G
IC110 6-707-739-01 IC MM1661JTRE
IC112 6-702-302-01 IC TK11133CSCL-G
IC201 6-704-524-01 IC FAN8036L
IC407 8-759-278-58 IC NJM4558V-TE2
<INDUCTOR>
L301 1-412-979-41 INDUCTOR 1UH
LF101 1-457-374-21 INDUCTOR 0UH
LF102 1-457-374-21 INDUCTOR 0UH
LF103 1-457-374-21 INDUCTOR 0UH
LF104 1-457-374-21 INDUCTOR 0UH
<FUSE>
PS502 1-576-892-11 FUSE 1A 0V
<TRANSISTOR>
Q101 6-550-008-01 TRANSISTOR UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-424-63 TRANSISTOR UN2212-TX
Q104 6-550-008-01 TRANSISTOR UM6K1N-TN
Q105 8-729-028-27 TRANSISTOR 2SK2009(TE85L)
Q401 8-729-038-12 TRANSISTOR RT1P141C-TP-1
Q402 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q403 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q405 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
* Q407 6-551-959-01 TRANSISTOR IMX25T110
Q411 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q417 8-729-038-22 TRANSISTOR RT1N140C-TP-1
<RESISTOR>
R102 1-216-864-91 SHORT CHIP 0
R103 1-208-659-81 METAL CHIP 100 0.5% 1/16W
R104 1-208-896-81 METAL CHIP 2.4K 0.5% 1/16W
R105 1-216-864-91 SHORT CHIP 0
R107 1-218-965-81 METAL CHIP 10K 5% 1/16W
R108 1-216-857-91 METAL CHIP 1M 5% 1/10W
R109 1-218-990-81 SHORT CHIP 0
R110 1-218-973-81 METAL CHIP 47K 5% 1/16W
R111 1-216-809-91 METAL CHIP 100 5% 1/10W
R112 1-211-977-91 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-91 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-91 METAL CHIP 100K 5% 1/10W
R115 1-211-977-91 METAL CHIP 22 0.5% 1/10W
R116 1-218-953-81 METAL CHIP 1K 5% 1/16W
R117 1-218-973-81 METAL CHIP 47K 5% 1/16W
R118 1-216-801-91 METAL CHIP 22 5% 1/10W
R120 1-216-801-91 METAL CHIP 22 5% 1/10W
R121 1-216-801-91 METAL CHIP 22 5% 1/10W
R122 1-216-864-91 SHORT CHIP 0
R123 1-218-990-81 SHORT CHIP 0
R124 1-218-973-81 METAL CHIP 47K 5% 1/16W
R125 1-218-990-81 SHORT CHIP 0
R126 1-218-965-81 METAL CHIP 10K 5% 1/16W
R127 1-218-961-81 METAL CHIP 4.7K 5% 1/16W
R128 1-218-961-81 METAL CHIP 4.7K 5% 1/16W
R130 1-218-965-81 METAL CHIP 10K 5% 1/16W
R131 1-216-864-91 SHORT CHIP 0
R132 1-216-864-91 SHORT CHIP 0
R133 1-218-973-81 METAL CHIP 47K 5% 1/16W
R136 1-216-864-91 SHORT CHIP 0
R137 1-218-990-81 SHORT CHIP 0
R138 1-218-961-81 METAL CHIP 4.7K 5% 1/16W
R139 1-216-864-91 SHORT CHIP 0
R140 1-216-824-91 METAL CHIP 1.8K 5% 1/10W
R142 1-216-845-91 METAL CHIP 100K 5% 1/10W
MV-60
The components identified by mark
or dotted line with mark are critical
for safety.
Replace only with part number
specified.
Notes:
MV-60 Board must be replaced if
IC103 (EEPROM) is damaged or not functioning.
The old MV-60 Board must be completely disposed.
