Sony SA-CT780 - Page 53

HT-CT780
53
IC604 MM3411A50NRE
IC1802 TPS2065CDBVR
IC605 BD00IC0WHFV-GTR
VOUT5
NC
4
CE 3
GND
2
VDD
1
+

VOLTAGE
REFERENCE
CURRENT
LIMIT
BIAS
456
2
1 3
VOUT
FB
GND
VCC N.C. EN
+
SOFT
START
OCP
TSD


1 CSOUT
FLT
3
GND
2
5IN
4EN
OTSD
CURRENT
SENSE
CURRENT
LIMIT
THERMAL
SENSE
9-MS
DEGLITCH
DRIVER
UVLO
CHARGE
PUMP
DISABLED
+UVLO
– FL Board –
IC803 MM3411A33URE
VOUT
3
CE 1
GND
2
VDD
4
+
–
VOLTAGE
REFERENCE
CURRENT
LIMIT
BIAS
– POWER Board –
IC930 STR-Y6735 (US, Canadian and Taiwan models)
IC930 STR-Y6766B (Except US, Canadian and Taiwan models)
D/ST 1
S/OCP
2
VCC
3
GND
4
BD
6
FB/OLP
5
STARTUP
LOGIC
DRIVER
LATCH
OVERCURRENT
PROTECTION/
BOTTOM-SKIP
UNDER VOLTAGE
LOCK OUT/
REGULATOR/
CONSTANT CURRENT
FEEDBACK/
STANDBY
OVERLOAD
PROTECTION
BOTTOM
DETECTION
NF 7
OSCILLAOTR
Ver. 1.1
