Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-CT780
74
R1075 1-218-941-81 METAL CHIP 100 5% 1/16W
R1076 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1077 1-218-941-81 METAL CHIP 100 5% 1/16W
R1078 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1079 1-218-941-81 METAL CHIP 100 5% 1/16W
R1080 1-218-941-81 METAL CHIP 100 5% 1/16W
R1081 1-218-941-81 METAL CHIP 100 5% 1/16W
R1089 1-218-941-81 METAL CHIP 100 5% 1/16W
R1091 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1093 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R1096 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R1097 1-218-941-81 METAL CHIP 100 5% 1/16W
R1098 1-218-941-81 METAL CHIP 100 5% 1/16W
R1104 1-218-990-81 SHORT CHIP 0
R1105 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R1106 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R1107 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R1108 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R1113 1-208-859-81 METAL CHIP 68 0.5% 1/16W
R1115 1-218-973-11 METAL CHIP 47K 5% 1/16W
R1116 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1117 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1120 1-218-981-81 METAL CHIP 220K 5% 1/16W
R1122 1-218-949-11 METAL CHIP 470 5% 1/16W
R1124 1-208-859-81 METAL CHIP 68 0.5% 1/16W
R1505 1-218-933-11 METAL CHIP 22 5% 1/16W
R1506 1-218-933-11 METAL CHIP 22 5% 1/16W
R1507 1-218-933-11 METAL CHIP 22 5% 1/16W
R1508 1-218-933-11 METAL CHIP 22 5% 1/16W
R1509 1-218-973-11 METAL CHIP 47K 5% 1/16W
R1510 1-218-973-11 METAL CHIP 47K 5% 1/16W
R1511 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R1512 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R1513 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R1514 1-218-937-11 METAL CHIP 47 5% 1/16W
R1515 1-218-937-11 METAL CHIP 47 5% 1/16W
R1516 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1517 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1518 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1519 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1520 1-218-933-11 METAL CHIP 22 5% 1/16W
R1521 1-218-933-11 METAL CHIP 22 5% 1/16W
R1522 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1523 1-218-929-11 METAL CHIP 10 5% 1/16W
R1524 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1525 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1526 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1527 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1528 1-218-929-11 METAL CHIP 10 5% 1/16W
R1529 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1530 1-218-933-11 METAL CHIP 22 5% 1/16W
R1531 1-218-933-11 METAL CHIP 22 5% 1/16W
R1532 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1533 1-218-929-11 METAL CHIP 10 5% 1/16W
R1535 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R1536 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R1537 1-218-973-11 METAL CHIP 47K 5% 1/16W
R1538 1-218-933-11 METAL CHIP 22 5% 1/16W
R1539 1-218-933-11 METAL CHIP 22 5% 1/16W
R1540 1-218-947-11 METAL CHIP 330 5% 1/16W
R1541 1-220-208-81 METAL CHIP 130K 5% 1/16W
R1543 1-218-937-11 METAL CHIP 47 5% 1/16W
R1544 1-218-937-11 METAL CHIP 47 5% 1/16W
R1545 1-218-937-11 METAL CHIP 47 5% 1/16W
R1546 1-218-945-11 METAL CHIP 220 5% 1/16W
R1547 1-218-937-11 METAL CHIP 47 5% 1/16W
R1549 1-218-937-11 METAL CHIP 47 5% 1/16W
R1551 1-218-937-11 METAL CHIP 47 5% 1/16W
R1552 1-218-937-11 METAL CHIP 47 5% 1/16W
R1553 1-218-937-11 METAL CHIP 47 5% 1/16W
R1554 1-216-864-11 SHORT CHIP 0
R1560 1-218-933-11 METAL CHIP 22 5% 1/16W
R1561 1-218-933-11 METAL CHIP 22 5% 1/16W
R1801 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1804 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1805 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1806 1-218-941-81 METAL CHIP 100 5% 1/16W
R1807 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1808 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1810 1-218-967-11 METAL CHIP 15K 5% 1/16W
R1811 1-218-967-11 METAL CHIP 15K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB101 1-234-375-21 RES, NETWORK 1K (1005X4)
RB102 1-234-372-11 RES, NETWORK 100 (1005X4)
RB103 1-234-372-11 RES, NETWORK 100 (1005X4)
RB104 1-234-372-11 RES, NETWORK 100 (1005X4)
RB105 1-234-372-11 RES, NETWORK 100 (1005X4)
RB107 1-234-372-11 RES, NETWORK 100 (1005X4)
RB108 1-234-372-11 RES, NETWORK 100 (1005X4)
RB501 1-234-372-11 RES, NETWORK 100 (1005X4)
RB502 1-234-372-11 RES, NETWORK 100 (1005X4)
* RB1001 1-460-611-11 COMMON MODE CHOKE COIL
* RB1002 1-460-611-11 COMMON MODE CHOKE COIL
* RB1015 1-460-611-11 COMMON MODE CHOKE COIL
* RB1016 1-460-611-11 COMMON MODE CHOKE COIL
RB1501 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1502 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1503 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1504 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
< VIBRATOR >
X101 1-781-646-21 VIBRATOR, CERAMIC (4 MHz)
X301 1-814-267-11 QUARTZ CRYSTAL UNIT (24.576 MHz)
X302 1-814-363-11 QUARTZ CRYSTAL UNIT (25 MHz)
X1501 1-814-595-11 QUARTS CRYSTAL UNIT (27 MHz)
*************************************************************
A-2066-054-A POWER BOARD, COMPLETE (US, CND, TW)
(See Note)
A-2066-056-A POWER BOARD, COMPLETE
(Except US, CND, TW) (See Note)
**********************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
0 C902 1-112-870-51 CERAMIC 0.001uF 20% 250V
(US, CND, TW) (See Note)
0 C902 1-118-332-11 CERAMIC 0.0033uF 20% 250V
(Except US, CND, TW) (See Note)
Note: When C902 on the POWER board and the complete POWER board are
replaced, refer to “BOND FIXATION OF ELECTRIC PARTS” on page 6.
MAIN POWER
Ver. 1.1
