Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-CT780
75
0 C903 1-112-870-51 CERAMIC 0.001uF 20% 250V
(US, CND, TW) (See Note)
0 C903 1-118-332-11 CERAMIC 0.0033uF 20% 250V
(Except US, CND, TW) (See Note)
0 C905 1-114-594-21 FILM 0.22uF 10% 310V
(US, CND, TW) (See Note)
0 C905 1-116-397-21 FILM 0.33uF 10% 310V
(Except US, CND, TW) (See Note)
0 C907 1-116-397-21 FILM 0.33uF 10% 310V
(Except US, CND, TW)
0 C914 1-100-922-11 ELECT 330uF 20% 200V
(US, CND, TW) (See Note)
0 C915 1-118-715-11 ELECT (BLOCK) 100uF 20 % 450V
(Except US, CND, TW) (See Note)
0 C930 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
0 C931 1-164-217-91 CERAMIC CHIP 150PF 5% 50V
(US, CND, TW)
0 C931 1-164-218-91 CERAMIC CHIP 180PF 5% 50V
(Except US, CND, TW)
0 C932 1-162-968-91 CERAMIC CHIP 0.0047uF 10% 50V
0 C933 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
0 C934 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
0 C935 1-117-824-11 FILM 2200PF 3% 1.5KV
(US, CND, TW)
0 C936 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
0 C937 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
0 C938 1-125-893-11 FILM 680PF 3% 1.5KV
(Except US, CND, TW)
0 C939 1-116-034-92 FILM 0.0033uF 5% 400V
0 C940 1-112-869-51 CERAMIC 470PF 10% 250V
(US, CND, TW)
0 C941 1-112-235-21 ELECT 330uF 20% 25V
(See Note)
C965 1-112-723-21 CERAMIC CHIP 0.0047uF 10% 250V
C967 1-114-994-11 ELECT 2200uF 20% 35V
(See Note)
C968 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C970 1-112-241-11 ELECT 1000uF 20% 25V
(See Note)
C971 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C976 1-112-245-21 ELECT 47uF 20% 35V
C977 1-112-245-21 ELECT 47uF 20% 35V
(See Note)
C978 1-126-964-11 ELECT 10uF 20% 50V
(Except US, CND, TW) (See Note)
C980 1-112-245-21 ELECT 47uF 20% 35V
(See Note)
0 C988 1-165-528-11 MYLAR 0.1uF 10% 250V
(US, CND, TW) (See Note)
< CONNECTOR >
0 * CN901 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
* CN902 1-564-725-11 PIN, CONNECTOR (SMALL TYPE) 9P
< DIODE >
0 D901 8-719-077-77 DIODE D3SB60F3 (See Note)
0 D930 6-503-032-01 DIODE DZ2J180M0L
0 D931 8-719-083-71 DIODE UDZSUSTE-1730B
0 D932 6-502-975-01 DIODE DZ2J15000L
0 D934 6-503-032-01 DIODE DZ2J180M0L
0 D935 8-719-083-71 DIODE UDZSUSTE-1730B
0 D936 6-501-119-01 DIODE RR264M-400
0 D937 6-501-119-01 DIODE RR264M-400
0 D938 6-503-731-01 DIODE SARS10
0 D939 6-503-037-01 DIODE DZ2J24000L
0 D941 8-719-083-71 DIODE UDZSUSTE-1730B
0 D942 6-503-775-01 DIODE CRH02 (T5R, SONY, XM)
D965 6-501-849-01 DIODE FMX-22SL
D967 6-503-978-01 DIODE RB068L100TE25
0 D972 6-502-264-01 DIODE KDZTR18B
D973 8-719-083-71 DIODE UDZSUSTE-1730B
< FUSE >
0 F901 1-523-067-51 FUSE (5 A/250 V)
0 F931 1-523-085-11 FUSE (2.5 A/250 V) (See Note)
< IC >
0 IC930
6-720-460-01 IC STR-Y6735 (US, CND, TW)
0 IC930 6-721-976-01 IC STR-Y6766B (Except US, CND, TW)
IC931 6-716-865-01 IC MM1431FNRE
< COIL >
L966 1-460-612-11 COIL, CHOKE 2.2uH
L967 1-481-175-21 INDUCTOR 4.7uH
< LINE FILTER >
0 LF901 1-445-944-11 TRANSFORMER, LINE FILTER
(Except US, CND, TW) (See Note)
0 LF901 1-460-693-11 LINE FILTER TRANSFORMER (US, CND, TW)
(See Note)
< PHOTO COUPLER >
0 PH930 6-600-883-01 PHOTO COUPLER EL816S1 (B) (TA) (DTE-S)
< TRANSISTOR >
0 Q930 8-729-056-46 TRANSISTOR 2SC5053T100Q
0 Q931 6-552-949-01 TRANSISTOR LTC044EUBFS8TL
Q950 6-550-586-01 TRANSISTOR 2PA1576R-115
(Except US, CND, TW)
* Q952 6-553-105-01 TRANSISTOR PDTC144EU
(Except US, CND, TW)
< RESISTOR >
0 R901 1-240-938-51 METAL 1.5M 5% 0.5W F
0 R914 1-248-270-15 FUSIBLE 0.33 10% 1W F
0 R932 1-216-345-51 METAL OXIDE 0.47 5% 1W F
(US, CND, TW)
0 R932 1-216-353-51 METAL OXIDE 2.2 5% 1W F
(Except US, CND, TW)
0 R934 1-248-050-11 METAL 0.22 5% 2W F
(Except US, CND, TW) (See Note)
0 R934 1-248-245-11 METAL 0.15 5% 2W F
(US, CND, TW) (See Note)
0 R935 1-216-825-91 METAL CHIP 2.2K 5% 1/10W
0 R936 1-216-841-91 METAL CHIP 47K 5% 1/10W
0 R937 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R938 1-216-838-91 METAL CHIP 27K 5% 1/10W
0 R944 1-215-927-51 METAL OXIDE 47K 5% 3W F
(US, CND, TW)
0 R944 1-215-929-51 METAL OXIDE 100K 5% 3W F
(Except US, CND, TW)
0 R945 1-216-809-91 METAL CHIP 100 5% 1/10W
0 R947 1-216-793-91 METAL CHIP 4.7 5% 1/10W
Note: When C903, C905, C914, C915, C941, C967, C970, C977, C978, C980, C988, D901, F931,
LF901 and R934 are replaced, refer to “BOND FIXATION OF ELECTRIC PARTS” on page 6.
POWER
Ver. 1.1
