2-8. CIRCUIT BOARDS LOCATION
2-4 E
MA-377
VIDEO, AUDIO, I/O,
SERVO/SYSTEM CONTROL,
TUNER, MODE CONTROL
FJ-26
(EX8S/EX9S)
(FRONT IN)
DS-92
(MODE CONTROL)
POWER BLOCK
(PSM17-501)
(POWER SUPPLY)
KK-24
(EASY TIMER, SEARCH)
MF-321
(POWER SWITCH)
(
)
