8-10
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
JS708 1-216-295-00 METAL CHIP 0 5% 1/10W
(EX8S/EX9S)
JS709 1-216-295-00 METAL CHIP 0 5% 1/10W
JS710 1-216-295-00 METAL CHIP 0 5% 1/10W
JS713 1-216-295-00 METAL CHIP 0 5% 1/10W
JS720 1-216-295-00 METAL CHIP 0 5% 1/10W
JS730 1-216-295-00 METAL CHIP 0 5% 1/10W
(EX8S/EX9S)
JS731 1-216-296-00 METAL CHIP 0 5% 1/8W
(EX5)
JS901 1-216-295-00 METAL CHIP 0 5% 1/10W
(EX8S/EX9S)
JS902 1-216-295-00 METAL CHIP 0 5% 1/10W
(EX8S/EX9S)
JS909 1-216-295-00 METAL CHIP 0 5% 1/10W
(EX5)
JS910 1-216-295-00 METAL CHIP 0 5% 1/10W
JS913 1-216-295-00 METAL CHIP 0 5% 1/10W
(EX8S/EX9S)
< COIL >
L151 1-414-185-51 INDUCTOR 22uH
L152 1-414-184-51 INDUCTOR 15uH
L171 1-414-185-51 INDUCTOR 22uH
L172 1-414-185-51 INDUCTOR 22uH
L202 1-414-856-51 INDUCTOR 10uH
L204 1-410-510-11 INDUCTOR 12uH
L205 1-410-521-11 INDUCTOR 100uH
L206 1-414-856-51 INDUCTOR 10uH
L207 1-414-856-51 INDUCTOR 10uH
L208 1-216-295-00 METAL CHIP 0 5% 1/10W
L209 1-216-295-00 METAL CHIP 0 5% 1/10W
L210 1-216-295-00 METAL CHIP 0 5% 1/10W
L214 1-414-856-51 INDUCTOR 10uH
L215 1-414-187-51 INDUCTOR 47uH
L301 1-414-857-51 INDUCTOR 100uH (EX8S/EX9S)
L302 1-414-857-51 INDUCTOR 100uH (EX8S/EX9S)
L351 1-414-857-51 INDUCTOR 100uH
L371 1-410-120-11 INDUCTOR 1.2mH
L700 1-414-856-51 INDUCTOR 10uH
L701 1-414-856-51 INDUCTOR 10uH
L702 1-414-856-51 INDUCTOR 10uH
L703 1-414-856-51 INDUCTOR 10uH
L704 1-414-187-51 INDUCTOR 47uH
L705 1-414-856-51 INDUCTOR 10uH (EX8S/EX9S)
L900 1-414-857-51 INDUCTOR 100uH (EX8S/EX9S)
L901 1-414-857-51 INDUCTOR 100uH
< FLUORESCENT INDICATOR >
ND451 1-517-734-11 TUBE, FLUORESCENT INDICATOR
< PHOTO INTERRUPTER >
PH001 8-749-013-23 PHOTO INTERRUPTER GP3S120 (T REEL)
PH002 8-749-013-23 PHOTO INTERRUPTER GP3S120 (S REEL)
< IC LINK >
0PS071 1-533-593-51 LINK, IC (2A)
0PS331 1-533-586-51 LINK, IC (315mA)
< TRANSISTOR >
Q001 8-729-043-84 TRANSISTOR PT380F3
Q002 8-729-043-84 TRANSISTOR PT380F3
Q003 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q153 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q172 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q174 8-729-421-22 TRANSISTOR UN2211-TX
Q203 8-729-421-19 TRANSISTOR UN2213-TX
Q206 8-729-421-19 TRANSISTOR UN2213-TX
Q210 8-729-421-19 TRANSISTOR UN2213-TX
Q211 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q337 8-729-216-21 TRANSISTOR 2SA1162Y-TE85L
(EX8S/EX9S)
Q338 8-729-230-49 TRANSISTOR 2SC2712Y-TE85L
(EX8S/EX9S)
Q339 8-729-230-49 TRANSISTOR 2SC2712Y-TE85L
(EX8S/EX9S)
Q372 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q373 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q374 8-729-901-06 TRANSISTOR MUN2113T1
Q375 8-729-012-31 TRANSISTOR 2SC4040-TL2-Q
Q376 8-729-900-51 TRANSISTOR UN2115-QRS (TX)
Q701 8-729-106-68 TRANSISTOR 2SD1664-T100-R
Q704 8-729-421-19 TRANSISTOR UN2213-TX (EX8S/EX9S)
Q706 8-729-421-19 TRANSISTOR UN2213-TX
Q707 8-729-804-41 TRANSISTOR 2SB1122-ST-TD
Q901 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
(EX8S/EX9S)
Q902 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q903 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
Q904 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX
(EX8S/EX9S)
< RESISTOR >
R001 1-249-413-11 CARBON 470 5% 1/4W
R003 1-249-421-11 CARBON 2.2K 5% 1/4W
R004 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R005 1-249-401-11 CARBON 47 5% 1/4W
R006 1-249-401-11 CARBON 47 5% 1/4W
R007 1-216-089-00 METAL CHIP 47K 5% 1/10W
R008 1-249-437-11 CARBON 47K 5% 1/4W
R009 1-249-435-11 CARBON 33K 5% 1/4W
R010 1-249-435-11 CARBON 33K 5% 1/4W
R032 1-216-089-00 METAL CHIP 47K 5% 1/10W
R033 1-216-077-91 RES-CHIP 15K 5% 1/10W
R051 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R052 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R053 1-247-843-11 CARBON 3.3K 5% 1/4W
R054 1-216-073-00 METAL CHIP 10K 5% 1/10W
R055 1-216-073-00 METAL CHIP 10K 5% 1/10W
R056 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R057 1-249-429-11 CARBON 10K 5% 1/4W
R071 1-216-103-00 METAL CHIP 180K 5% 1/10W
R072 1-216-089-00 METAL CHIP 47K 5% 1/10W
R073 1-216-049-00 METAL CHIP 1K 5% 1/10W
R074 1-216-049-00 METAL CHIP 1K 5% 1/10W
R075 1-216-049-00 METAL CHIP 1K 5% 1/10W
R076 1-216-049-00 METAL CHIP 1K 5% 1/10W
MA-377
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number speci-
fied.
