Sony SLV-EX50 - Video Block Diagram

SLV - EX50/EX80S/EX90S
3-2. VIDEO BLOCK DIAGRAM
3-3 3-4
320mVp-p (H)
IC201
y;
REC/PB
REC:512mVp-p (H)
PB :584mVp-p (H)
IC201
tk
REC/PB
IC291
4
PB
2.2Vp-p (H)
IC291
w;
PB
152mVp-p (H)
IC291
4
REC
2.1Vp-p (H)
2.36Vp-p (15.7KHz)
IC101
ql
REC/PB
2.16Vp-p (15.7KHz)
IC101
qj
REC/PB
IC201
t;
REC/PB
4.6Vp-p (H)
IC201
e;
REC/PB
1.1Vp-p (H)
IC201
wa
REC/PB
392mVp-p (H)
IC201
qk,ql
REC/PB
REC:472mVp-p (H)
PB :504mVp-p (H)
IC201
wh
REC/PB
REC:512mVp-p (H)
PB :584mVp-p (H)
IC201
wd
REC/PB
REC:472mVp-p (H)
PB :504mVp-p (H)
IC201
ug
REC/PB
496mVp-p (4.43MHz)(PAL)
IC201
ua
REC/PB
608mVp-p
(3.58MHz)(NTSC)
40mVp-p (H)
IC201
ih,il
REC
IC201
ia
REC/PB
5.3Vp-p (H)
640mVp-p (H)
IC201
uk
PB
720mVp-p (H)
IC201
ul
PB
