SLV-LX80S
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
8-6
8-2. ELECTRICAL PARTS LIST
* A-6713-943-A DI-081 BOARD COMPLETE
*********************
<CONNECTOR>
CN901 1-695-368-31 CONNECTOR, FFC/FPC 7P
CN901 1-784-449-11 CONNECTOR, FFC/FPC 7P
<DIODE>
D900 8-719-056-06 DIODE SLR-342DCT31
<RESISTOR>
R900 1-216-295-00 SHORT 0
R902 1-216-043-91 RES-CHIP 560 5% 1/10W
<SWITCH>
S900 1-762-196-21 SWITCH, TACT (SEARCH)
S901 1-418-059-22 ENCODER, ROTARY (CAM ENCODER)
* A-6713-942-A DM-098 BOARD COMPLETE
**********************
<CONNECTOR>
CN471 1-770-514-31 CONNECTOR, FFC/FPC 5P
CN471 1-784-447-11 CONNECTOR, FFC/FPC 5P
<CHIP CONDUCTOR>
JR461 1-216-295-00 SHORT 0
<RESISTOR>
R465 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R467 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R468 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R469 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R470 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R474 1-216-295-00 SHORT 0
R475 1-216-295-00 SHORT 0
<SWITCH>
S462 1-762-196-21 SWITCH, TACT (AEJECT)
S463 1-762-196-21 SWITCH, TACT (zREC)
S466 1-762-196-21 SWITCH, TACT (mREW)
S467 1-762-196-21 SWITCH, TACT (xSTOP)
S468 1-762-196-21 SWITCH, TACT (HPLAY)
S469 1-762-196-21 SWITCH, TACT (MFF)
S472 1-762-196-21 SWITCH, TACT (XPAUSE)
* A-6713-949-A FJ-031 BOARD COMPLETE (SLV-EX50)
* A-6713-947-A FJ-031 BOARD COMPLETE (SLV-EX80S)
* A-6713-941-A FJ-031 BOARD COMPLETE (SLV-EX90S)
********************
<CONNECTOR>
CN532 1-695-368-31 CONNECTOR, FFC/FPC 7P
CN532 1-784-449-11 CONNECTOR, FFC/FPC 7P
<JACK>
CNJ5311-770-021-11 JACK, PIN 3P (SLV-EX80S/EX90S)
<DIODE>
D531 8-719-071-15 DIODE HZM6.8ZWA1TL
(SLV-EX80S/EX90S)
D532 8-719-071-15 DIODE HZM6.8ZWA1TL
(SLV-EX80S/EX90S)
D533 8-719-071-15 DIODE HZM6.8ZWA1TL
(SLV-EX80S/EX90S)
D534 8-719-017-09 DIODE 02DZ6.2-TPH3
(SLV-EX80S/EX90S)
<JUMPER SELECTOR>
JS531 1-216-296-00 SHORT 0 (SLV-EX80S/EX90S)
JS532 1-216-296-00 SHORT 0 (SLV-EX80S/EX90S)
JS534 1-216-295-00 SHORT 0 (SLV-EX80S/EX90S)
JS535 1-216-295-00 SHORT 0 (SLV-EX80S)
DI-81 DM-98 FJ-31
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark or
dotted line with mark
are critical for safety.
Replace only with part number specified.
