SLV-LX80S
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
8-9
MA-402
C351 1-163-038-00 CERAMIC CHIP 0.1UF 25V
C352 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
C354 1-124-234-00 ELECT 22UF 20.00% 16V
C355 1-126-157-11 ELECT 10UF 20.00% 16V
C356 1-163-011-11 CERAMIC CHIP 0.0015UF 10.00% 50V
C357 1-163-011-11 CERAMIC CHIP 0.0015UF 10.00% 50V
(SLV-EX50AR/EX80SAR/EX90SAR)
C357 1-163-014-00 CERAMIC CHIP 0.0027UF 10.00% 50V
(SLV-EX50BR/EX80SBR/EX90SBR)
C358 1-126-163-11 ELECT 4.7UF 20.00% 50V
C359 1-126-157-11 ELECT 10UF 20.00% 16V
C361 1-126-160-11 ELECT 1UF 20.00% 50V
C362 1-126-160-11 ELECT 1UF 20.00% 50V
(SLV-EX50)
C363 1-124-234-00 ELECT 22UF 20.00% 16V
C364 1-126-163-11 ELECT 4.7UF 20.00% 50V
C365 1-164-232-11 CERAMIC CHIP 0.01UF 10.00% 50V
C371 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
C373 1-137-505-11 MYLAR 220PF 5.00% 50V
C375 1-104-696-11 FILM 0.015UF 5.00% 100V
C376 1-163-011-11 CERAMIC CHIP 0.0015UF 10.00% 50V
C377 1-162-306-11 CERAMIC 0.01UF 20.00% 16V
C378 1-124-589-11 ELECT 47UF 20.00% 16V
C379 1-163-038-00 CERAMIC CHIP 0.1UF 25V
C385 1-126-160-11 ELECT 1UF 20.00% 50V
(SLV-EX80S/EX90S)
C386 1-126-160-11 ELECT 1UF 20.00% 50V
(SLV-EX80S/EX90S)
C451 1-124-584-00 ELECT 100UF 20.00% 10V
C452 1-164-232-11 CERAMIC CHIP 0.01UF 10.00% 50V
C453 1-126-157-11 ELECT 10UF 20.00% 16V
C454 1-163-038-00 CERAMIC CHIP 0.1UF 25V
C455 1-124-584-00 ELECT 100UF 20.00% 10V
C456 1-164-232-11 CERAMIC CHIP 0.01UF 10.00% 50V
C457 1-126-941-11 ELECT 470UF 20.00% 25V
C600 1-104-705-11 MYLAR 0.1UF 20.00% 250V
C601 1-104-705-11 MYLAR 0.1UF 20.00% 250V
C602 1-113-900-11 CERAMIC 470PF 10.00% 250V
C603 1-113-900-11 CERAMIC 470PF 10.00% 250V
C604 1-113-900-11 CERAMIC 470PF 10.00% 250V
C605 1-107-405-11 ELECT(BLOCK) 68UF 20.00% 400V
(SLV-EX50AR/EX80SAR/EX90SAR)
C605 1-125-917-11 ELECT(BLOCK) 100UF 20.00% 450V
(SLV-EX50BR/EX80SBR/EX90SBR)
C606 1-130-470-00 MYLAR 820PF 5.00% 50V
C607 1-107-737-11 MYLAR 560PF 5.00% 50V
C608 1-131-974-11 FILM 2200PF 5% 800V
C610 1-137-921-11 ELECT 1500UF 20% 10V
C611 1-126-935-11 ELECT 470UF 20.00% 16V
C612 1-126-960-11 ELECT 1UF 20.00% 50V
C613 1-130-496-00 MYLAR 0.12UF 5.00% 50V
C615 1-131-976-21 ELECT 820UF 20% 25V
C616 1-126-941-11 ELECT 470UF 20.00% 25V
C624 1-126-967-11 ELECT 47UF 20.00% 50V
C626 1-126-967-11 ELECT 47UF 20.00% 50V
C627 1-164-232-11 CERAMIC CHIP 0.01UF 10.00% 50V
C629 1-135-372-31 ELECT 470UF 20% 10V
C630 1-164-232-11 CERAMIC CHIP 0.01UF 10.00% 50V
C631 1-164-232-11 CERAMIC CHIP 0.01UF 10.00% 50V
C633 1-164-232-11 CERAMIC CHIP 0.01UF 10.00% 50V
C636 1-126-967-11 ELECT 47UF 20.00% 50V
C661 1-164-232-11 CERAMIC CHIP 0.01UF 10.00% 50V
C662 1-104-666-11 ELECT 220UF 20.00% 25V
C663 1-126-941-11 ELECT 470UF 20.00% 25V
C664 1-124-589-11 ELECT 47UF 20.00% 16V
C665 1-124-234-00 ELECT 22UF 20.00% 16V
C669 1-164-232-11 CERAMIC CHIP 0.01UF 10.00% 50V
C671 1-126-965-91 ELECT 22UF 20.00% 50V
C673 1-164-232-11 CERAMIC CHIP 0.01UF 10.00% 50V
C674 1-126-933-11 ELECT 100UF 20.00% 16V
C704 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
C705 1-164-232-11 CERAMIC CHIP 0.01UF 10.00% 50V
C706 1-126-933-11 ELECT 100UF 20.00% 16V
C707 1-126-947-11 ELECT 47UF 20.00% 25V
C708 1-126-163-11 ELECT 4.7UF 20.00% 50V
C709 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
C710 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
C711 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
C712 1-126-933-11 ELECT 100UF 20.00% 16V
C713 1-164-232-11 CERAMIC CHIP 0.01UF 10.00% 50V
C714 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
C715 1-163-989-11 CERAMIC CHIP 0.033UF 10.00% 25V
(SLV-EX50)
C719 1-163-038-00 CERAMIC CHIP 0.1UF 25V
(SLV-EX80S/EX90S)
C720 1-126-157-11 ELECT 10UF 20.00% 16V
(SLV-EX80S/EX90S)
C722 1-126-933-11 ELECT 100UF 20.00% 16V
(SLV-EX80S/EX90S)
C723 1-164-232-11 CERAMIC CHIP 0.01UF 10.00% 50V
(SLV-EX80S/EX90S)
C901 1-126-160-11 ELECT 1UF 20.00% 50V
(SLV-EX80S/EX90S)
C902 1-126-160-11 ELECT 1UF 20.00% 50V
(SLV-EX80S/EX90S)
C903 1-126-935-11 ELECT 470UF 20.00% 10V
C907 1-124-589-11 ELECT 47UF 20.00% 16V
<CONNECTOR>
CN031*1-766-716-11 CONNECTOR, BOARD TO BOARD 3P
CN051 1-794-861-11 CONNECTOR, BOARD TO BOARD 8P
CN072 1-766-978-31 CONNECTOR, FFC/FPC 5P
CN072 1-784-484-11 CONNECTOR, FFC/FPC 5P
CN105 1-506-470-11 PIN, CONNECTOR 5P
CN201 1-766-984-41 CONNECTOR, FFC/FPC 11P
(SLV-EX80S/EX90S)
CN202*1-560-892-00 PIN, CONNECTOR 4P
CN204 1-691-038-31 HOUSING, CONNECTOR 6P (SLV-EX50)
CN331 1-766-980-71 CONNECTOR, FFC/FPC 7P
CN331 1-784-486-11 CONNECTOR, FFC/FPC 7P
CN332 1-506-468-11 PIN, CONNECTOR 3P
CN332 1-506-468-11 PIN, CONNECTOR 3P
CN334 1-766-980-71 CONNECTOR, FFC/FPC 7P
CN334 1-784-486-11 CONNECTOR, FFC/FPC 7P
CN411 1-766-980-71 CONNECTOR, FFC/FPC 7P
CN411 1-784-486-11 CONNECTOR, FFC/FPC 7P
CN412 1-766-978-31 CONNECTOR, FFC/FPC 5P
Note :
The components identified by
mark
or dotted line with mark
are critical for safety.
Replace only with part number
specified.
