Index to parts and control (continued)
Display window
1 8 mm tape indicator
2 8 mm tape speed indicator
3 VTR indicator
4 REMAIN indicator (32)
5 DEW indicator (62)
6 Video8 indicator
7 VPS/PDC indicator (40)
8 VHS indicator
9 MAIN/L/SUB/R indicator (46)
!… STEREO indicator (46)
!` OPC indicator (50)
!“ VHS speed indicator (32)
!£ VHS tape indicator
!¢ Channel indicator (31)
!∞ NICAM indicator (46)
!⁄ RF indicator (12)
!ƒ Clock/quick timer remaining time
(43)
!¥ Time counter/clock (30)
STEREO OPC SP LP
NICAM
VHSVTRSP LP video8
VPS PDCDEWREMAIN
MAIN/L
SUB/R
H M S
1
234
5
6
7
89
0
!`
!“
!£
!¥
!ƒ
!¢
!
RF
!⁄
