Operating a Single Camera Using the Optional Remote
Controller
What you can do with this system
Perform pan/tilt and zoom operations using the joystick of the remote controller.
System Configuration
• The illustration of the remote controller features the RM-IP500 (sold separately) remote controller.
• Turn on switch number 3 on the CAMERA SETUP switch when using VISCA communication.
Remote controller
Video monitor
Video signal
Remote Control (VISCA) signal
Signal flow
