Menu Configuration
The camera menu is configured as described below. For more details, refer to the pages in parenthesis.
The initial settings of each item are in bold. Only supported functions are displayed.
Menu item Setting item Setting value
EXPOSURE
(page 30)
MODE FULL AUTO,
SHUTTER Pri, IRIS Pri, MANUAL
GAIN 0dB,
3dB, 6dB, 9dB, 12dB, 15dB, 18dB, 21dB, 24dB, 27dB, 30dB, 33dB, 36dB
(When high-sensitivity mode is set to OFF)
0dB,
3dB, 6dB, 9dB, 12dB, 15dB, 18dB, 21dB, 24dB, 27dB, 30dB, 33dB, 36dB,
39dB, 42dB, 45dB, 48dB (When high-sensitivity mode is set to ON)
(Adjustable only when MODE in the EXPOSURE menu is set to MANUAL.)
SPEED For the 59.94 or 29.97 frame rate of video output:
1/1, 2/3, 1/2, 1/3, 1/4, 1/6, 1/8, 1/10, 1/15, 1/20, 1/30, 1/50, 1/60, 1/90, 1/100,
1/125, 1/180, 1/250, 1/350, 1/500, 1/725, 1/1000, 1/1500, 1/2000, 1/3000,
1/4000, 1/6000, 1/10000
For the 50 or 25 frame rate of video output:
1/1, 2/3, 1/2, 1/3, 1/4, 1/6, 1/8, 1/12, 1/15, 1/20, 1/25, 1/30, 1/50, 1/60, 1/100,
1/120, 1/150, 1/215, 1/300, 1/425, 1/600, 1/1000, 1/1250, 1/1750, 1/2500,
1/3500, 1/6000, 1/10000
For the 23.98 frame rate of video output:
1/1, 2/3, 1/2, 1/3, 1/4, 1/6, 1/8, 1/12, 1/20, 1/24, 1/25, 1/40, 1/48, 1/50, 1/60,
1/96, 1/100, 1/120, 1/144, 1/192, 1/200, 1/288, 1/400, 1/576, 1/1200, 1/2400,
1/4800, 1/10000
(Adjustable only when MODE in the EXPOSURE menu is set to MANUAL or
SH
UTTER Pri.)
IRIS F2.0/F2.2/F2.4/F2.6/F2.8/F3.1/F3.4/F3.7/F4.0/F4.4/F4.8/F5.2/F5.6/F6.2/
F6.8/F7.3/F8.0/F8.7/F9.6/F10/F11/CLOSE
(Adjustable only when MODE in the EXPOSURE menu is set to MANUAL or IRIS
Pr
i.)
AE SPEED 1 ~ 48
(Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO,
S
HUTTER Pri, or IRIS Pri.)
EX-COMP OFF, O
N
(Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO,
S
HUTTER Pri, or IRIS Pri.)
LEVEL -7, -6, -5, -4, -3, -2, -1, 0, +1, +2, +3, +4, +5, +6, +7
(Adjustable when MODE in the EXPOSURE menu is set to FULL AUTO,
S
HUTTER Pri, or IRIS Pri, and EX COMP is set to ON.)
GAIN LIMIT 9dB, 12dB, 15dB, 18dB, 21dB,
24dB, 27dB, 30dB, 33dB, 36dB (When high-
sensitivity mode is set to OFF)
21dB, 24dB, 27dB, 30dB, 33dB,
36dB, 39dB, 42dB, 45dB, 48dB (When high-
sensitivity mode is set to ON)
(Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO,
S
HUTTER Pri, or IRIS Pri.)
GAIN POINT OFF, ON
(Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO or
I
RIS Pri.)
POINT POSITION 0dB,
3dB, 6dB, 9dB, 12dB, 15dB, 18dB, 21dB, 24dB, 27dB, 30dB, 33dB, 36dB
(When high-sensitivity mode is set to OFF)
0dB,
3dB, 6dB, 9dB, 12dB, 15dB, 18dB, 21dB, 24dB, 27dB, 30dB, 33dB, 36dB,
39dB, 42dB, 45dB, 48dB (When high-sensitivity mode is set to ON)
(Adjustable when MODE in the EXPOSURE menu is set to FULL AUTO or IRIS
P
ri, and GAIN POINT is set to ON.)
MAX SPEED For the 59.94 or 29.97 frame rate of video output:
1/30, 1/50, 1/60, 1/90, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/725, 1/1000,
1/1500, 1/2000, 1/3000, 1/4000, 1/6000, 1/10000
For the 50 or 25 frame rate of video output:
1/25, 1/30, 1/50, 1/60, 1/100, 1/120, 1/150, 1/215, 1/300, 1/425, 1/600, 1/1000,
1/
1250, 1/1750, 1/2500, 1/3500, 1/6000, 1/10000
For the 23.98 frame rate of video output:
1/24, 1/25, 1/40, 1/48, 1/50, 1/60, 1/96, 1/100, 1/120, 1/144, 1/192, 1/200,
1/288, 1/400, 1/576, 1/1200, 1/2400, 1/4800, 1/10000
(Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO or
I
RIS Pri.)
