— 79 —
Pin Name
MODE 0
MODE 1
MODE 2
HSTX
STOP
IR-IN (A6)
—
—
AUBUS IN
V. SIGNAL
SIRCS-IN
VD
AUBUS OUT
V-MUT
—
—
—
—
—
IR ON/OFF
BUSY
RESET
GND
XO
XI
VCC
AD00 to AD13
Pin No.
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67 to 100
I/O
I
I
I
I
I
I
–
–
I
I
I
I
O
O
O
–
–
–
–
O
O
I
–
O
I
–
I/O
Function
Mode setting (Fixed at “H”)
Mode setting (Fixed at “L”)
Mode setting (Fixed at “L”)
Hardware standby (Fixed at “H”)
Request input of reset interrupt
IR sensor remote control input (Not used)
Not used
Not used
S–LINK control A1 signal input
H–sync switching signal input
SIRCS signal input
PAL: 60 [flame/s]/ NTSC: 50 [flame/s] signal detect VD input
S–LINK control A1 signal output
To control output into monitor (Not used)
Image mute output (Not used)
Not used
Not used
Not used
Not used
IR remote control ON/OFF output “H” off
Input/output to communicate with the display control
Reset signal input
Ground
Clock (4 MHz)
Clock (4 MHz)
Power supply (+5.6V)
Address bus and data bus input/output
