Sony STR-D760Z - Components Identified by Mark! or Dotted Line

— 95 —
R2008 1-249-429-11 CARBON 10K 5% 1/4W
R2015 1-247-807-31 CARBON 100 5% 1/4W
R2016 1-249-429-11 CARBON 10K 5% 1/4W
R2017 1-249-429-11 CARBON 10K 5% 1/4W
R2018 1-249-429-11 CARBON 10K 5% 1/4W
R2019 1-249-429-11 CARBON 10K 5% 1/4W
R2020 1-247-807-31 CARBON 100 5% 1/4W
R2031 1-247-807-31 CARBON 100 5% 1/4W
R2032 1-247-807-31 CARBON 100 5% 1/4W
R2033 1-247-807-31 CARBON 100 5% 1/4W
R2034 1-247-807-31 CARBON 100 5% 1/4W
R2035 1-247-807-31 CARBON 100 5% 1/4W
R2036 1-247-807-31 CARBON 100 5% 1/4W
R2037 1-247-807-31 CARBON 100 5% 1/4W
R2038 1-247-807-31 CARBON 100 5% 1/4W
R2039 1-247-807-31 CARBON 100 5% 1/4W
R2040 1-247-807-31 CARBON 100 5% 1/4W
R2041 1-247-807-31 CARBON 100 5% 1/4W
R2042 1-247-807-31 CARBON 100 5% 1/4W
R2043 1-247-807-31 CARBON 100 5% 1/4W
R2044 1-247-807-31 CARBON 100 5% 1/4W
R2045 1-247-807-31 CARBON 100 5% 1/4W
R2046 1-247-807-31 CARBON 100 5% 1/4W
R2047 1-247-807-31 CARBON 100 5% 1/4W
R2048 1-247-807-31 CARBON 100 5% 1/4W
R2049 1-247-807-31 CARBON 100 5% 1/4W
R2050 1-247-807-31 CARBON 100 5% 1/4W
R2051 1-247-807-31 CARBON 100 5% 1/4W
R2052 1-247-807-31 CARBON 100 5% 1/4W
R2053 1-247-807-31 CARBON 100 5% 1/4W
< TEST PIN >
* TP204 1-560-062-00 PIN, CONNECTOR 4P
TP205 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< VIBRATOR >
X201 1-567-819-11 VIBRATOR, CERAMIC (4MHz)
X205 1-567-776-41 VIBRATOR, CERAMIC (6MHz)
**************************************************************
* 1-665-497-11 SECONDARY BOARD
**************
< CAPACITOR >
C801 1-126-967-11 ELECT 47uF 20% 16V
C805 1-130-781-00 FILM 0.22uF 10% 100V
(SP,MY,AUS)
C805 1-137-420-11 FILM 0.047uF 10% 100V
(US,CND,E,PX)
C806 1-130-781-00 FILM 0.22uF 10% 100V
(SP,MY,AUS)
C806 1-137-420-11 FILM 0.047uF 10% 100V
(US,CND,E,PX)
< CONNECTOR >
* CNP801 1-564-905-11 PIN, CONNECTOR 9P
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< COIL >
L288 1-410-521-11 INDUCTOR 100uH
L289 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q201 8-729-900-36 TRANSISTOR DTC124ES
Q204 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q205 8-729-119-76 TRANSISTOR 2SA1175-HFE (DE815G:US,CND)
Q209 8-729-620-05 TRANSISTOR 2SC2603-EF (DE815G:US,CND)
Q212 8-729-620-05 TRANSISTOR 2SC2603-EF (DE815G:US,CND)
Q220 8-729-620-05 TRANSISTOR 2SC2603-EF
Q222 8-729-119-76 TRANSISTOR 2SA1175-HFE (DE815G:US,CND)
Q223 8-729-620-05 TRANSISTOR 2SC2603-EF (DE815G:US,CND)
Q225 8-729-119-76 TRANSISTOR 2SA1175-HFE (DE815G:US,CND)
Q226 8-729-119-76 TRANSISTOR 2SA1175-HFE (DE815G:US,CND)
< RESISTOR >
R1 1-249-413-11 CARBON 470 5% 1/4W F
(DE815G:US,CND)
R2 1-249-413-11 CARBON 470 5% 1/4W F
(DE815G:US,CND)
R6 1-247-843-11 CARBON 3.3K 5% 1/4W
(DE815G:US,CND)
R7 1-249-429-11 CARBON 10K 5% 1/4W
(DE815G:US,CND)
R208 1-249-419-11 CARBON 1.5K 5% 1/4W F
R209 1-249-429-11 CARBON 10K 5% 1/4W
R221 1-249-414-11 CARBON 560 5% 1/4W F
(DE815G:US,CND)
R222 1-249-414-11 CARBON 560 5% 1/4W F
(DE815G:US,CND)
R224 1-249-433-11 CARBON 22K 5% 1/4W
(DE815G:US,CND)
R225 1-249-427-11 CARBON 6.8K 5% 1/4W F
(DE815G:US,CND)
R229 1-249-417-11 CARBON 1K 5% 1/4W F
(DE815G:US,CND)
R231 1-249-417-11 CARBON 1K 5% 1/4W F
R235 1-249-429-11 CARBON 10K 5% 1/4W
R241 1-249-417-11 CARBON 1K 5% 1/4W F
(DE815G:US,CND)
R245 1-249-417-11 CARBON 1K 5% 1/4W F
(DE815G:US,CND)
R249 1-249-413-11 CARBON 470 5% 1/4W F
R256 1-249-417-11 CARBON 1K 5% 1/4W F
(DE815G:US,CND)
R284 1-247-843-11 CARBON 3.3K 5% 1/4W
R286 1-247-903-00 CARBON 1M 5% 1/4W
R291 1-249-429-11 CARBON 10K 5% 1/4W
R292 1-249-393-11 CARBON 10 5% 1/4W F
R293 1-249-429-11 CARBON 10K 5% 1/4W
R294 1-249-425-11 CARBON 4.7K 5% 1/4W F
R295 1-249-425-11 CARBON 4.7K 5% 1/4W F
R297 1-247-843-11 CARBON 3.3K 5% 1/4W
(DE815G:US,CND)
R298 1-249-429-11 CARBON 10K 5% 1/4W
(DE815G:US,CND)
R299 1-249-417-11 CARBON 1K 5% 1/4W F
(DE815G:US,CND)
! R2001 1-215-857-11 METAL OXIDE 10 5% 1W F
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
