— 94 —
Q757 8-749-010-26 IC MP1620-OPY-M
Q758 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
< RESISTOR >
R701 1-249-417-11 CARBON 1K 5% 1/4W F
R702 1-249-439-11 CARBON 68K 5% 1/4W
R703 1-249-439-11 CARBON 68K 5% 1/4W
R704 1-247-820-11 CARBON 360 5% 1/4W
(SP,MY)
R704 1-249-411-11 CARBON 330 5% 1/4W
(EXCEPT SP,MY)
R721 1-249-437-11 CARBON 47K 5% 1/4W
R722 1-249-421-11 CARBON 2.2K 5% 1/4W F
R723 1-249-414-11 CARBON 560 5% 1/4W F
! R724 1-249-408-11 CARBON 180 5% 1/4W F
! R725 1-249-408-11 CARBON 180 5% 1/4W F
! R726 1-233-352-41 ENCAPSULATED COMPONENT
R727 1-247-850-11 CARBON 6.2K 5% 1/4W
R728 1-249-419-11 CARBON 1.5K 5% 1/4W F
R732 1-249-437-11 CARBON 47K 5% 1/4W
R751 1-249-417-11 CARBON 1K 5% 1/4W F
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-249-439-11 CARBON 68K 5% 1/4W
R754 1-247-820-11 CARBON 360 5% 1/4W
(SP,MY)
R754 1-249-411-11 CARBON 330 5% 1/4W
(EXCEPT SP,MY)
R771 1-249-437-11 CARBON 47K 5% 1/4W
R772 1-249-421-11 CARBON 2.2K 5% 1/4W F
R773 1-249-414-11 CARBON 560 5% 1/4W F
! R774 1-249-408-11 CARBON 180 5% 1/4W F
! R775 1-249-408-11 CARBON 180 5% 1/4W F
! R776 1-233-352-41 ENCAPSULATED COMPONENT
R777 1-247-850-11 CARBON 6.2K 5% 1/4W
R778 1-249-419-11 CARBON 1.5K 5% 1/4W F
R782 1-249-437-11 CARBON 47K 5% 1/4W
R790 1-249-417-11 CARBON 1K 5% 1/4W F
R793 1-249-435-11 CARBON 33K 5% 1/4W
R794 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R798 1-249-393-11 CARBON 10 5% 1/4W F
! R799 1-249-393-11 CARBON 10 5% 1/4W F
**************************************************************
* 1-665-503-11 S-A-P BOARD
***********
< CONNECTOR >
CNP703 1-695-089-11 PIN, CONNECTOR (PC BOARD) 11P
CNS702 1-695-096-11 SOCKET, CONNECTOR 15P
CNS905 1-695-092-11 SOCKET, CONNECTOR 7P
**************************************************************
* A-4398-131-A S.VIDEO BOARD, COMPLETE (DE815G:US,CND)
**************************************
* A-4398-139-A S.VIDEO BOARD, COMPLETE
************************
(EXCEPT DE815G:US,CND)
< CAPACITOR >
C204 1-164-159-11 CERAMIC 0.1uF 50V
C221 1-126-964-11 ELECT 10uF 20% 50V
C222 1-162-294-31 CERAMIC 0.001uF 10% 50V
C232 1-162-306-11 CERAMIC 0.01uF 20% 16V
C238 1-126-967-11 ELECT 47uF 20% 16V
C239 1-164-159-11 CERAMIC 0.1uF 50V
C246 1-164-159-11 CERAMIC 0.1uF 50V
C261 1-102-074-00 CERAMIC 0.001uF 10% 50V
(DE815G:US,CND)
C269 1-164-159-11 CERAMIC 0.1uF 50V
C270 1-124-252-00 ELECT 0.33uF 20% 50V
C274 1-126-967-11 ELECT 47uF 20% 16V
C275 1-126-967-11 ELECT 47uF 20% 16V
C276 1-104-905-11 CAPACITOR 0.22F 5.5V
C277 1-162-306-11 CERAMIC 0.01uF 20% 16V
C280 1-164-159-11 CERAMIC 0.1uF 50V
C295 1-164-159-11 CERAMIC 0.1uF 50V
C297 1-126-923-11 ELECT 220uF 20% 10V
C2001 1-126-967-11 ELECT 47uF 20% 16V
C2238 1-102-074-00 CERAMIC 0.001uF 10% 50V
(DE815G:US,CND)
< CONNECTOR >
CNJ203 1-568-440-11 SOCKET, CONNECTOR 17P
CNJ204 1-779-768-11 SOCKET, CONNECTOR 29P
* CNJ214 1-564-509-11 PLUG, CONNECTOR 6P
CNS211 1-695-094-11 SOCKET, CONNECTOR 11P
CNS213 1-750-179-11 SOCKET, CONNECTOR 5P
< DIODE >
D202 8-719-987-63 DIODE 1N4148M
D203 8-719-987-63 DIODE 1N4148M
D204 8-719-987-63 DIODE 1N4148M
D205 8-719-024-99 DIODE 11ES2-NTA2B
D210 8-719-987-63 DIODE 1N4148M
< IC >
IC201 8-759-135-80 IC uPC358C (DE815G:US,CND)
IC207 8-759-708-05 IC NJM78L05A
IC209 8-759-426-13 IC MB90672PF-G-125-BND
IC215 8-759-457-57 IC LC86F5864A-5E72
IC217 8-759-604-35 IC M5F78M05L
IC219 8-759-917-18 IC SN74HCU04AN
IC223 8-759-388-26 IC NJM2129D (DE815G:US,CND)
< JACK >
J202 1-563-330-11 JACK (S-LINK CTRL A1)
J212 1-563-330-11 JACK (VIDEO 1 CTRL SOUT)(DE815G:US,CND)
J213 1-563-330-11 JACK (VIDEO 2 CTRL SOUT)(DE815G:US,CND)
J214 1-563-330-11 JACK (MONITOR CTRL SOUT)(DE815G:US,CND)
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
REAR AMP
S-A-P S.VIDEO
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
