— 97 —
R744 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DE815G)
R745 1-249-421-11 CARBON 2.2K 5% 1/4W F
(DE815G)
R746 1-249-421-11 CARBON 2.2K 5% 1/4W F
(DE815G)
R747 1-249-429-11 CARBON 10K 5% 1/4W
R748 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R749 1-249-393-11 CARBON 10 5% 1/4W F
R783 1-249-393-11 CARBON 10 5% 1/4W F
(DE815G)
! R784 1-249-389-11 CARBON 4.7 5% 1/4W F
R787 1-249-429-11 CARBON 10K 5% 1/4W
(DE815G)
R788 1-247-886-11 CARBON 200K 5% 1/4W
(DE815G)
< RELAY >
RY503 1-515-793-11 RELAY
RY601 1-515-920-11 RELAY (24V)
RY701 1-515-920-11 RELAY (24V)
< SWITCH >
S501 1-692-196-11 SWITCH, SLIDE (IMPEDANCE SELECTOR)
(EXCEPT SP,MY)
< TERMINAL >
* TM701 1-537-882-11 TERMINAL BOARD 6P (SURROUND SPEAKERS)
**************************************************************
* 1-665-626-11 SP SW BOARD
***********
< CONNECTOR >
* CNS101 1-695-808-11 CONNECTOR, PC BOARD 8P
< DIODE >
D152 8-719-987-63 DIODE 1N4148M
D153 8-719-987-63 DIODE 1N4148M
< SWITCH >
S136 1-762-751-11 SWITCH, TACTILE (DPC MODE)
S152 1-554-118-00 SWITCH, PUSH (1 KEY)(POWER)(SP,MY)
S155 1-762-268-11 SWITCH, ROTARY (SPEAKERS)
**************************************************************
* A-4398-127-A STAND BY BOARD, COMPLETE (US,CND)
**********************************
* A-4398-138-A STAND BY BOARD, COMPLETE (E,PX)
********************************
* A-4398-145-A STAND BY BOARD, COMPLETE (SP,MY)
*********************************
* A-4398-150-A STAND BY BOARD, COMPLETE (AUS)
*******************************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C901 1-161-494-00 CERAMIC 0.022uF 25V
C902 1-161-494-00 CERAMIC 0.022uF 25V
C903 1-126-768-11 ELECT 2200uF 20% 16V
C904 1-126-960-11 ELECT 1uF 20% 50V
C905 1-126-959-11 ELECT 0.47uF 20% 50V
C906 1-124-464-11 ELECT 0.22uF 20% 50V
C913 1-164-159-11 CERAMIC 0.1uF 50V
C914 1-164-159-11 CERAMIC 0.1uF 50V
C917 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
! CNJ901 1-540-060-11 OUTLET, AC (POLAR)(AC OUTLET)
(US,CND,E,PX)
CNP903 1-564-321-00 PIN, CONNECTOR 2P
* CNP904 1-580-230-21 PIN, CONNECTOR (PC BOARD) 2P (SP,MY,AUS)
CNP905 1-695-087-11 PIN, CONNECTOR (PC BOARD) 7P
* CNP906 1-564-687-11 PIN, CONNECTOR 3P (E,PX)
CNP908 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P (E,PX)
< DIODE >
D901 8-719-024-99 DIODE 11ES2-NTA2B
D902 8-719-024-99 DIODE 11ES2-NTA2B
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
D905 8-719-987-63 DIODE 1N4148M
D906 8-719-987-63 DIODE 1N4148M
D907 8-719-987-63 DIODE 1N4148M
< GROUND TERMINAL >
* EB900 1-537-738-21 TERMINAL, EARTH
< FUSE >
! F901 1-532-504-51 FUSE TIME-LAG (T4.6AL/250V)(EXCEPT US,CND)
! F901 1-533-311-11 FUSE (8A/125V)(US,CND)
! F902 1-532-464-51 FUSE TIME-LAG (T2.5AL/250V)(SP,MY,AUS)
! F903 1-532-504-51 FUSE TIME-LAG (T4.0AL/250V)(E,PX)
< FUSE HOLDER >
FH901 1-533-217-31 HOLDER, FUSE
FH902 1-533-217-31 HOLDER, FUSE (SP,MY,AUS)
FH903 1-533-217-31 HOLDER, FUSE (E,PX)
FH951 1-533-217-31 HOLDER, FUSE
FH952 1-533-217-31 HOLDER, FUSE (SP,MY,AUS)
FH953 1-533-217-31 HOLDER, FUSE (E,PX)
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
