— 86 —
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
CND : Canadian model
SP : Singapore model
MY : Malaysia model
AUS : Australian model
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
Note:
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C570 1-126-967-11 ELECT 47uF 20% 16V
C571 1-107-597-11 CERAMIC 22PF 10% 500V
C572 1-107-597-11 CERAMIC 22PF 10% 500V
C573 1-162-286-31 CERAMIC 220PF 10% 50V
C574 1-126-964-11 ELECT 10uF 20% 50V
C575 1-136-157-00 FILM 0.022uF 5% 50V
C576 1-136-153-00 FILM 0.01uF 5% 50V
C590 1-126-935-11 ELECT 470uF 20% 6.3V
C598 1-126-965-11 ELECT 22uF 20% 50V
C620 1-126-967-11 ELECT 47uF 20% 16V
C621 1-107-597-11 CERAMIC 22PF 10% 500V
C622 1-107-597-11 CERAMIC 22PF 10% 500V
C623 1-162-286-31 CERAMIC 220PF 10% 50V
C803 1-109-932-11 ELECT 10000uF 20% 71V
(EXCEPT SP,MY)
C803 1-117-203-11 ELECT 10000uF 20% 63V
(SP,MY)
C804 1-109-932-11 ELECT 10000uF 20% 71V
(EXCEPT SP,MY)
C804 1-117-203-11 ELECT 10000uF 20% 63V
(SP,MY)
C807 1-126-967-11 ELECT 47uF 20% 16V
C808 1-126-967-11 ELECT 47uF 20% 16V
C810 1-126-967-11 ELECT 47uF 20% 16V
C811 1-126-952-11 ELECT 1000uF 20% 35V
C812 1-126-951-11 ELECT 470uF 20% 35V
C817 1-126-967-11 ELECT 47uF 20% 50V
C818 1-126-967-11 ELECT 47uF 20% 50V
< CONNECTOR >
CNP701 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
CNP702 1-695-091-11 PIN, CONNECTOR (PC BOARD) 15P
CNS502 1-770-404-11 HOUSING,CONNECTOR (PC BOARD) 11P
CNS602 1-770-404-11 HOUSING,CONNECTOR (PC BOARD) 11P
CNS701 1-569-323-11 SOCKET, CONNECTOR 19P
< DIODE >
D501 8-719-987-63 DIODE 1N4148M
D502 8-719-010-06 DIODE UZ-2.2BS
D503 8-719-010-06 DIODE UZ-2.2BS
D504 8-719-987-63 DIODE 1N4148M
D505 8-719-987-63 DIODE 1N4148M
D506 8-719-987-63 DIODE 1N4148M
D512 8-719-987-63 DIODE 1N4148M
D545 8-719-987-63 DIODE 1N4148M
D546 8-719-987-63 DIODE 1N4148M
D547 8-719-987-63 DIODE 1N4148M
* 1-665-629-11 5.1 IN BOARD
************
< CONNECTOR >
CNP305 1-564-524-11 PLUG, CONNECTOR 9P
< JACK >
J306 1-779-355-11 JACK, PIN 6P (5.1 INPUT)
< RESISTOR >
R317 1-249-421-11 CARBON 2.2K 5% 1/4W F
R325 1-249-421-11 CARBON 2.2K 5% 1/4W F
R326 1-249-421-11 CARBON 2.2K 5% 1/4W F
R327 1-249-429-11 CARBON 10K 5% 1/4W
R328 1-249-429-11 CARBON 10K 5% 1/4W
R329 1-249-429-11 CARBON 10K 5% 1/4W
R367 1-249-421-11 CARBON 2.2K 5% 1/4W F
R375 1-249-421-11 CARBON 2.2K 5% 1/4W F
R376 1-249-421-11 CARBON 2.2K 5% 1/4W F
R377 1-249-429-11 CARBON 10K 5% 1/4W
R378 1-249-429-11 CARBON 10K 5% 1/4W
R379 1-249-429-11 CARBON 10K 5% 1/4W
**************************************************************
* A-4398-108-A AMP BOARD, COMPLETE
********************
(DE815G:US,CND,E,PX)
* A-4398-140-A AMP BOARD, COMPLETE (SP,MY)
****************************
* A-4398-152-A AMP BOARD, COMPLETE (D760Z)
****************************
* A-4398-189-A AMP BOARD, COMPLETE (AUS)
**************************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C520 1-126-967-11 ELECT 47uF 20% 16V
C521 1-107-597-11 CERAMIC 22PF 10% 500V
C522 1-107-597-11 CERAMIC 22PF 10% 500V
C523 1-162-286-31 CERAMIC 220PF 10% 50V
C524 1-126-964-11 ELECT 10uF 20% 50V
C525 1-136-157-00 FILM 0.022uF 5% 50V
C526 1-136-153-00 FILM 0.01uF 5% 50V
SECTION 7
ELECTRICAL PARTS LIST
5.1 IN
AMP
