— 96 —
< DIODE >
D801 8-719-302-38 DIODE RBV-602-01
D802 8-719-024-99 DIODE 11ES2-NTA2B
D803 8-719-024-99 DIODE 11ES2-NTA2B
D804 8-719-024-99 DIODE 11ES2-NTA2B
D805 8-719-024-99 DIODE 11ES2-NTA2B
D806 8-719-014-66 DIODE UZP-5.6B
< FUSE >
! F950 1-532-506-51 FUSE, TIME-LAG (T6.3AL/250V)
(EXCEPT US,CND)
! F950 1-533-311-11 FUSE (8A/125V) (US,CND)
! F951 1-532-506-51 FUSE, TIME-LAG (T6.3AL/250V)
(EXCEPT US,CND)
! F951 1-533-311-11 FUSE (8A/125V) (US,CND)
! PS801 1-533-909-31 FUSE, MICRO (4A/125V)(US,CND)
! PS802 1-533-909-31 FUSE, MICRO (4A/125V)(US,CND)
**************************************************************
* A-4398-129-A SP BOARD, COMPLETE (EXCEPT D760Z,SP,MY)
**************************************
* A-4398-146-A SP BOARD, COMPLETE (SP,MY)
***************************
* A-4398-154-A SP BOARD, COMPLETE (D760Z)
***************************
< CAPACITOR >
C624 1-126-964-11 ELECT 10uF 20% 50V
C625 1-136-157-00 FILM 0.022uF 5% 50V
C626 1-136-153-00 FILM 0.01uF 5% 50V
C724 1-126-964-11 ELECT 10uF 20% 50V
C725 1-136-157-00 FILM 0.022uF 5% 50V
C726 1-136-153-00 FILM 0.01uF 5% 50V
C775 1-136-157-00 FILM 0.022uF 5% 50V
C794 1-126-964-11 ELECT 10uF 20% 50V
(DE815G)
C795 1-126-941-11 ELECT 470uF 20% 25V
(DE815G)
< CONNECTOR >
CNP603 1-564-320-00 PIN, CONNECTOR 2P
CNS703 1-695-094-11 SOCKET, CONNECTOR 11P
CNJ701 1-774-136-11 CONNECTOR, ROUND TYPE 6P
(WIRELESS REAR SPEAKER)(DE815G)
< DIODE >
D500 8-719-987-63 DIODE 1N4148M
D543 8-719-987-63 DIODE 1N4148M
D605 8-719-987-63 DIODE 1N4148M
D606 8-719-987-63 DIODE 1N4148M
D607 8-719-987-63 DIODE 1N4148M
D649 8-719-987-63 DIODE 1N4148M
D705 8-719-987-63 DIODE 1N4148M
D706 8-719-987-63 DIODE 1N4148M
D749 8-719-987-63 DIODE 1N4148M
< IC >
IC702 8-759-605-01 IC M5F78M18L (DE815G)
< JACK >
J501 1-770-377-31 JACK, PIN 1P (WOOFER)
< COIL >
L601 1-420-872-00 COIL, AIR-CORE (EXCEPT SP,MY)
L601 1-411-906-11 COIL, AIR-CORE (SP,MY)
L701 1-420-872-00 COIL, AIR-CORE (EXCEPT SP,MY)
L701 1-411-906-11 COIL, AIR-CORE (SP,MY)
L751 1-420-872-00 COIL, AIR-CORE (EXCEPT SP,MY)
L751 1-411-906-11 COIL, AIR-CORE (SP,MY)
< TRANSISTOR >
Q544 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q609 8-729-281-53 TRANSISTOR 2SC1815-GR
Q610 8-729-900-63 TRANSISTOR DTA124ES
Q611 8-729-900-63 TRANSISTOR DTA124ES
Q645 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q709 8-729-281-53 TRANSISTOR 2SC1815-GR
Q710 8-729-900-63 TRANSISTOR DTA124ES
Q745 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q747 8-729-119-79 TRANSISTOR 2SC2785-FEK (DE815G)
Q748 8-729-030-19 TRANSISTOR 2SB1640 (DE815G)
< RESISTOR >
R543 1-249-429-11 CARBON 10K 5% 1/4W
R544 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R545 1-249-393-11 CARBON 10 5% 1/4W F
R546 1-249-421-11 CARBON 2.2K 5% 1/4W F
R629 1-249-437-11 CARBON 47K 5% 1/4W
R630 1-249-421-11 CARBON 2.2K 5% 1/4W F
R631 1-249-433-11 CARBON 22K 5% 1/4W
R633 1-249-393-11 CARBON 10 5% 1/4W F
(DE815G)
! R634 1-249-389-11 CARBON 4.7 5% 1/4W F
R635 1-249-431-11 CARBON 15K 5% 1/4W
R636 1-249-433-11 CARBON 22K 5% 1/4W
R646 1-249-434-11 CARBON 27K 5% 1/4W F
R647 1-249-429-11 CARBON 10K 5% 1/4W
R648 1-249-425-11 CARBON 4.7K 5% 1/4W F
R649 1-249-393-11 CARBON 10 5% 1/4W F
(DE815G)
R729 1-249-437-11 CARBON 47K 5% 1/4W
R730 1-249-421-11 CARBON 2.2K 5% 1/4W F
R731 1-249-433-11 CARBON 22K 5% 1/4W
R733 1-249-393-11 CARBON 10 5% 1/4W F
(DE815G)
! R734 1-249-389-11 CARBON 4.7 5% 1/4W F
R735 1-249-431-11 CARBON 15K 5% 1/4W
R737 1-249-429-11 CARBON 10K 5% 1/4W
(DE815G)
R738 1-247-886-11 CARBON 200K 5% 1/4W
(DE815G)
R743 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DE815G)
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
