— 88 —
R597 1-249-434-11 CARBON 27K 5% 1/4W F
R598 1-249-434-11 CARBON 27K 5% 1/4W F
R621 1-247-840-00 CARBON 2.4K 5% 1/4W
R623 1-249-414-11 CARBON 560 5% 1/4W F
! R624 1-249-408-11 CARBON 180 5% 1/4W F
! R625 1-249-408-11 CARBON 180 5% 1/4W F
! R626 1-233-352-41 ENCAPSULATED COMPONENT
R627 1-247-850-11 CARBON 6.2K 5% 1/4W
R628 1-249-419-11 CARBON 1.5K 5% 1/4W F
R632 1-249-437-11 CARBON 47K 5% 1/4W
! R640 1-216-450-00 METAL OXIDE 82 5% 2W F
(EXCEPT SP,MY)
R641 1-249-441-11 CARBON 100K 5% 1/4W
(EXCEPT SP,MY)
! R642 1-215-889-00 METAL OXIDE 330 5% 2W F
R643 1-249-441-11 CARBON 100K 5% 1/4W
! R644 1-215-890-11 METAL OXIDE 470 5% 2W F
(EXCEPT SP,MY)
R645 1-249-441-11 CARBON 100K 5% 1/4W
(EXCEPT SP,MY)
R650 1-249-425-11 CARBON 4.7K 5% 1/4W F
R651 1-249-429-11 CARBON 10K 5% 1/4W
! R652 1-249-393-11 CARBON 10 5% 1/4W F
! R739 1-215-868-00 METAL OXIDE 680 5% 1W F
! R789 1-215-868-00 METAL OXIDE 680 5% 1W F
! R802 1-249-401-11 CARBON 47 5% 1/4W F
R803 1-247-843-11 CARBON 3.3K 5% 1/4W
< RELAY >
RY501 1-515-920-11 RELAY (24V)
RY502 1-515-920-11 RELAY (24V)
RY602 1-515-793-11 RELAY
< TERMINAL >
* TM501 1-537-519-11 TERMINAL BOARD (SP)(FRONT SPEAKER)
**************************************************************
* 1-665-633-11 AMP.JOINT (F) BOARD
*******************
< CONNECTOR >
CNP501 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
CNP502 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
**************************************************************
* 1-665-634-11 AMP.JOINT (R) BOARD
*******************
< CONNECTOR >
CNP601 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
CNP602 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
**************************************************************
* A-4398-116-A AUDIO BOARD, COMPLETE
**********************
< CAPACITOR >
C398 1-162-282-31 CERAMIC 100PF 10% 50V
C399 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
CNS302 1-695-093-11 SOCKET, CONNECTOR 9P
< IC >
IC303 8-759-805-14 IC LC7822
< JACK >
J304 1-770-015-11 JACK, PIN 6P
(VIDEO 1 AUDIO IN/OUT, VIDEO 2 AUDIO IN)
J305 1-774-411-11 JACK, PIN 6P
(VIDEO 2 AUDIO OUT, LD/DVD AUDIO IN,TV/DVS AUDIO IN)
< RESISTOR >
R318 1-249-417-11 CARBON 1K 5% 1/4W F
R319 1-249-417-11 CARBON 1K 5% 1/4W F
R320 1-249-417-11 CARBON 1K 5% 1/4W F
R321 1-249-417-11 CARBON 1K 5% 1/4W F
R322 1-249-425-11 CARBON 4.7K 5% 1/4W F
R323 1-249-417-11 CARBON 1K 5% 1/4W F
R338 1-249-437-11 CARBON 47K 5% 1/4W
R368 1-249-417-11 CARBON 1K 5% 1/4W F
R369 1-249-417-11 CARBON 1K 5% 1/4W F
R370 1-249-417-11 CARBON 1K 5% 1/4W F
R371 1-249-417-11 CARBON 1K 5% 1/4W F
R372 1-249-425-11 CARBON 4.7K 5% 1/4W F
R373 1-249-417-11 CARBON 1K 5% 1/4W F
R388 1-249-437-11 CARBON 47K 5% 1/4W
R398 1-249-417-11 CARBON 1K 5% 1/4W F
R399 1-249-425-11 CARBON 4.7K 5% 1/4W F
**************************************************************
* 1-665-495-11 AUDIO SW BOARD
***************
< CAPACITOR >
C407 1-126-795-11 ELECT 10uF 20% 50V
C408 1-164-159-11 CERAMIC 0.1uF 50V
C409 1-126-795-11 ELECT 10uF 20% 50V
C411 1-126-795-11 ELECT 10uF 20% 50V
C412 1-164-159-11 CERAMIC 0.1uF 50V
C457 1-126-795-11 ELECT 10uF 20% 50V
C458 1-164-159-11 CERAMIC 0.1uF 50V
C459 1-126-795-11 ELECT 10uF 20% 50V
C461 1-126-795-11 ELECT 10uF 20% 50V
C495 1-162-294-31 CERAMIC 0.001uF 10% 50V
C496 1-164-070-11 CERAMIC 100PF 5% 50V
C498 1-126-786-11 ELECT 47uF 20% 16V
C499 1-126-786-11 ELECT 47uF 20% 16V
Les composants identifiés par
une marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
AMP
AMP.JOINT (F) AMP.JOINT (R) AUDIO AUDIO SW
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
